SQJB90EPwww.vishay.comVishay SiliconixAutomotive Dual N-Channel 80 V (D-S) 175 C MOSFETFEATURESPowerPAK SO-8L Dual TrenchFET power MOSFET AEC-Q101 qualifiedD1 100 % Rg and UIS tested Material categorization: D2for definitions of compliance please see1S1 www.vishay.com/doc?999122G13S24D1D211 G2Top View Bottom ViewPRODUCT SUMMARYG1G2VDS (V) 80RDS(on) () at VGS = 10 V 0.0215ID (A) per leg 30S1Configuration DualS2Package PowerPAK SO-8L N-Channel MOSFET N-Channel MOSFETABSOLUTE MAXIMUM RATINGS (TC = 25 C, unless otherwise noted)PARAMETER SYMBOL LIMIT UNITDrain-Source Voltage VDS 80V Gate-Source Voltage VGS 20TC = 25 C a 30Continuous Drain Current IDTC = 125 C 18Continuous Source Current (Diode conduction) a IS 30 APulsed Drain Current b IDM 80Single Pulse Avalanche Curren
