SQM50020ELwww.vishay.comVishay SiliconixAutomotive N-Channel 60 V (D-S) 175 C MOSFETFEATURESPRODUCT SUMMARY TrenchFET power MOSFETVDS (V) 60 Package with low thermal resistanceRDS(on) () at VGS = 10 V 0.0020 AEC-Q101 qualifiedRDS(on) () at VGS = 4.5 V 0.0025 100 % Rg and UIS testedID (A) 120Configuration Single Material categorization:for definitions of compliance please seewww.vishay.com/doc?99912 DTO-263GSSSDDGGTop ViewN-Channel MOSFETORDERING INFORMATIONPackage TO-263Lead (Pb)-free and Halogen-free SQM50020EL-GE3ABSOLUTE MAXIMUM RATINGS (TC = 25 C, unless otherwise noted)PARAMETER SYMBOL LIMIT UNITDrain-Source Voltage VDS 60V Gate-Source Voltage VGS 20TC = 25 C 120Continuous Drain Current a IDTC = 125 C 120Continuous Source Current (Diode Conduction) a IS 120 APulsed
