SQM50N04-4m0Lwww.vishay.comVishay SiliconixAutomotive N-Channel 40 V (D-S) 175 C MOSFETFEATURESPRODUCT SUMMARY TrenchFET Power MOSFETVDS (V) 40 Package with Low Thermal ResistanceRDS(on) () at VGS = 10 V 0.0040 100 % Rg and UIS TestedRDS(on) () at VGS = 4.5 V 0.0055 AEC-Q101 QualifieddID (A) 50 Material categorization:Configuration SingleFor definitions of compliance please see www.vishay.com/doc?99912 DTO-263GG D STop ViewSN-Channel MOSFETORDERING INFORMATIONPackage TO-263Lead (Pb)-free and Halogen-free SQM50N04-4m0L-GE3ABSOLUTE MAXIMUM RATINGS (TC = 25 C, unless otherwise noted)PARAMETER SYMBOL LIMIT UNITDrain-Source Voltage VDS 40V Gate-Source Voltage VGS 20TC = 25 C 50Continuous Drain Currenta IDTC = 125 C 50Continuous Source Current (Diode Conduction)a IS 50 APulsed Drai
