SQM50P04-09Lwww.vishay.comVishay SiliconixAutomotive P-Channel 40 V (D-S) 175 C MOSFETFEATURESPRODUCT SUMMARY TrenchFET Power MOSFETVDS (V) - 40 Package with Low Thermal ResistanceRDS(on) () at VGS = - 10 V 0.0094 100 % Rg and UIS TestedRDS(on) () at VGS = - 4.5 V 0.0170 AEC-Q101 QualifieddID (A) - 50 Material categorization:Configuration SingleFor definitions of compliance please see www.vishay.com/doc?99912 STO-263GG D STop ViewDP-Channel MOSFETORDERING INFORMATIONPackage TO-263Lead (Pb)-free and Halogen-free SQM50P04-09L-GE3ABSOLUTE MAXIMUM RATINGS (TC = 25 C, unless otherwise noted)PARAMETER SYMBOL LIMIT UNITDrain-Source Voltage VDS - 40V Gate-Source Voltage VGS 20TC = 25 C - 50Continuous Drain Currenta IDTC = 125 C - 50Continuous Source Current (Diode Conduction)a IS - 50
