ST13007High voltage fast-switching NPN power transistorFeatures DC current gain classificationTAB High voltage capability Low spread of dynamic parameters Very high switching speedApplications 321 Electronic ballast for fluorescent lightingTO-220 Switch mode power suppliesDescriptionFigure 1. Internal schematic diagramThe device is manufactured using high voltage multi-epitaxial planar technology for high switching speeds and high voltage capability.It uses a cellular emitter structure with planar edge termination to enhance switching speeds while maintaining the wide RBSOA.Table 1. Device summaryOrder code Marking (1) Package Packaging ST13007AST13007 TO-220 Tube ST13007B1. The product is classified in DC current gain group A and group B, see Table 5: hFE classification. STMicroelectronics reserves the right to
