Скачать даташит для std13007fc:

STD13007FCNPN Silicon Power TransistorSWITCHING REGULATOR APPLICATIONS Features PIN Connection High speed switching High Collector Voltage : VCBO = 700V C Suitable for Switching Regulator and Motor Control BOrdering Information Type NO. Marking Package Code B C E STD13007FC STD13007 TO-220F-3SLEAbsolute maximum ratings (Tc=25) Characteristic Symbol Rating UnitCollector-Base voltage VCBO 700 VCollector-Emitter voltage VCEO 400 VEmitter-base voltage VEBO 9 VCollector current (DC) IC 8 ACollector current (Pulse) ICM 16 ABase current (DC) IB 4 ACollector Power dissipation (Tc=25) PC 40 WJunction temperature Tj 150 C Storage temperature Tstg -55~150 C Characteristic Symbol Typ. Max UnitJunction-case Rth(J-C) - 3.12Thermal /W resistance Junction-ambient Rth(J-a) - 62.5KSD-T0T006-001 1 STD13007FC
