STP9527 P Channel Enhancement Mode MOSFET -10.0A suSCRIPTION STP9527 is the P-Channel logic enhancement mode power field effect transistor which is produced using high cell density, DMOS trench technology. This high density process is especially tailored to minimize on-state resistance. These devices are particularly suited for low voltage application, noteook power management ane ther battery powered circuits where high-side witching.FEATURE PIN CONFIGURATION SOP-8 l -40V/-10.0A, R = 32m (Typ.) DS(ON) @VGS =-10V l -40V/-8.0A, R = 38m DS(ON)@VGS = -4.5V l Super high density cell design for extremely low R DS(ON) l Exceptional on-resistance and maximum DC current capability l SOP-8 package design PART MARKING SOP-8 STANSON TECHNOLOGY 120 Bentley Square, Mountain View, Ca 94040 USA www.stansontech.com Copyright 2007, Sta
