Скачать даташит для sts9013:

STS9013NPN Silicon TransistorDescriptions PIN Connection General purpose application. C Switching application. BFeatures Excellent hFE linearity. E Complementary pair with STS9012 TO-92 Ordering Information Type NO. Marking Package Code STS9013 STS9013 TO-92 Absolute maximum ratings (Ta=25C) Characteristic Symbol Ratings UnitCollector-Base voltage VCBO 40 VCollector-Emitter voltage VCEO 30 VEmitter-Base voltage VEBO 5 VCollector current IC 500 mAEmitter current IE -500 mA Collector dissipation PC 625 mWJunction temperature Tj 150 C Storage temperature Tstg -55~150 C Electrical Characteristics (Ta=25C) Characteristic Symbol Test Condition Min. Typ. Max. UnitCollector cut-off current ICBO VCB=35, IE=0 - - 0.1 A Emitter cut-off current IEBO VEB=5V, IC=0 - - 0.1 A DC current gain hFE* VCE=1V, IC=5
