STW22N95K5Automotive-grade N-channel 950 V, 0.280 typ., 17.5 A Zener-protected SuperMESH 5 Power MOSFETDatasheet - production dataFeatures Order code VDS RDS(on)max ID PTOTSTW22N95K5 950 V 0.330 17.5 A 250 W Designed for automotive applications and AEC-Q101 qualified3 Worldwide best FOM (figure of merit)21 Ultra low gate chargeTO-247 100% avalanche tested Zener-protectedApplications Switching applicationsFigure 1. Internal schematic diagram D(2)DescriptionThis device is an N-channel Power MOSFET developed using SuperMESH 5 technology. This revolutionary, avalanche-rugged, high voltage Power MOSFET technology is based on G(1)an innovative proprietary vertical structure. The result is a drastic reduction in on-resistance and ultra low gate charge for applications which require superior power densit
