SUM70060Ewww.vishay.comVishay SiliconixN-Channel 100 V (D-S) MOSFETFEATURESPRODUCT SUMMARY ThunderFET power MOSFETVDS (V) RDS(on) () MAX. ID (A) Qg (TYP.) Maximum 175 C junction temperature0.0056 at VGS = 10 V 131100 53.5 nC 100 % Rg and UIS tested0.0062 at VGS = 7.5 V 129 Material categorization:for definitions of compliance please see TO-263 www.vishay.com/doc?99912APPLICATIONSD Power supplies: - Uninterruptible power supplies - AC/DC switch-mode power supplies - Lighting SSG Synchronous rectificationDDGG DC/DC converterTop View Motor drive switchOrdering Information:S DC/AC inverterSUM70060E-GE3 (lead (Pb)-free and halogen-free)N-Channel MOSFET Battery managementABSOLUTE MAXIMUM RATINGS (TC = 25 C, unless otherwise noted)PARAMETER SYMBOL LIMIT UNITD
