TGH40N120F2DRField Stop Trench IGBTTO-247Features 1200V Field Stop Trench IGBT Technology High Speed Switching Low Conduction Loss Positive Temperature Coefficient Easy Parallel Operation 175 Operating Temperature Short Circuit Withstanding Time 5s RoHS Compliant JEDEC QualificationG C EApplicationsUPS, Welder, Inverter, Solar, PTC HeaterDevice Package Marking RemarkTGH40N120F2DR TO-247 TGH40N120F2DR RoHSAbsolute Maximum Ratings Parameter Symbol Value UnitCollector-Emitter Voltage VCES 1200 VGate-Emitter Voltage VGES 25 VTC = 25 80 AContinuous Collector Current ICTC = 100 40 APulsed Collector Current (Note 1) ICM 120 ADiode Continuous Forward Current TC = 100 IF 40 ADiode Pulsed Current (Note 2) IFM 120 ATC = 25 625 WPower Dissipation PDTC = 100 312 WOperating Junction T
