TIP31A/31B/31CTIP32A/32B/32CCOMPLEMENTARY SILICON POWERTRANSISTORSn TIP31A, TIP31C, TIP32A,TIP32B, ANDTIP32C ARE SGS-THOMSON PREFERREDSALESTYPESDESCRIPTIONThe TIP31A, TIP31B and TIP31C are siliconepitaxial-base NPN power transistors in JedecTO-220 plastic package, intented for use inmedium power linear and switching applications.32The complementary PNP types are TIP32A,1TIP32B and TIP32C.TO-220INTERNAL SCHEMATIC DIAGRAMABSOLUTE MAXIMUM RATINGSSymbol Parameter Value UnitNPN TIP31A TIP31B TIP31CPNP TIP32A TIP32B TIP32CV Collector-Base Voltage (I = 0) 60 80 100 VCBO EV Collector-Emitter Voltage (I = 0) 60 80 100 VCEO BVEBO Emitter-Base Voltage (IC = 0) 5 VIC Collector Current 3 AI Collector Peak Current 5 ACMI Base Current 1 ABP Total Dissipation at T 25 oC 40 Wtot caseTamb 25 oC 2 WoTstg Storage Temperatur
