UNISONIC TECHNOLOGIES CO., LTD TIP42C PNP PLANAR TRANSISTOR PNP EPITAXIAL PLANAR TRANSISTOR DESCRIPTION The UTC TIP42C is a PNP epitaxial planar transistor, designed for using in general purpose amplifier and switching applications. FEATURES * Complement to TIP41C ORDERING INFORMATION Ordering Number Pin Assignment Package Packing Lead Free Halogen Free 1 2 3TIP42CL-x-TA3-T TIP42CG-x-TA3-T TO-220 B C E TubeTIP42CL-x-TF3-T TIP42CG-x-TF3-T TO-220F B C E TubeTIP42CL-x-TN3-R TIP42CG-x-TN3-R TO-252 B C E Tape ReelTIP42CL-x-TN3-T TIP42CG-x-TN3-T TO-252 B C E TubeTIP42CL-x-TQ2-R TIP42CG-x-TQ2-R TO-263 B C E Tape ReelTIP42CL-x-TQ2-T TIP42CG-x-TQ2-T TO-263 B C E TubeNote: Pin Assignment: B: Base C: Case E: Emitter MARKING www.unisonic.com.tw 1 of 3 Copyright 2018 Unisonic Technologies Co., Ltd QW-R203-007.G TIP42C PNP PLANAR T
