TS13007B High Voltage NPN Transistor TO-220 Pin Definition: PRODUCT SUMMARY 1. Base BVCEO 400V 2. Collector 3. Emitter BVCBO 700V IC 8A VCE(SAT) 3V @ IC / IB = 8A / 2A Features Block Diagram High Voltage High Speed Switching Structure Silicon Triple Diffused Type NPN Silicon Transistor Ordering Information Part No. Package Packing TS13007BCZ C0 TO-220 50pcs / Tube Absolute Maximum Rating (Ta = 25oC unless otherwise noted) Parameter Symbol Limit Unit Collector-Base Voltage VCBO 700V V Collector-Emitter Voltage VCEO 400V V Emitter-Base Voltage VEBO 9 V DC 8 Collector Current IC A Pulse 16 DC 4 Base Current IB A Pulse 8 Total Power Dissipation @ TC=25C PTOT 80 W o Operating Junction Temperature TJ +150 C o Operating Junction and Storage Temperature Range TSTG - 55 to +150 C Note: Single Pu
