UNISONIC TECHNOLOGIES CO., LTD UTT100N05 Preliminary Power MOSFET 100A, 50V N-CHANNEL POWER MOSFET DESCRIPTION The UTC UTT100N05 is an N-channel enhancement mode power MOSFET using UTCs advanced technology to provide customers with minimum on-state resistance and superior switchingperformance. FEATURES * RDS(ON)= 7m @ VGS=10V, ID= 50A RDS(ON)= 10m @ VGS=4.5V, ID=50A * High switching speed * Improved dv/dt capability ORDERING INFORMATION Ordering Number Pin Assignment Package PackingLead Free Halogen Free 1 2 3 UTT100N05L-TA3-T UTT100N05G-TA3-T TO-220 G D S TubeNote: Pin Assignment: G: Gate D: Drain S: Source www.unisonic.com.tw 1 of 3 Copyright 2011 Unisonic Technologies Co., Ltd QW-R502-688.a UTT100N05 Preliminary Power MOSFET ABSOLUTE MAXIMUM RATINGS PARAMETER SYMBOL RATINGS UNITDrain-Source Voltage VDSS 50 VG
