UNISONIC TECHNOLOGIES CO., LTD UTT100N08 Preliminary Power MOSFET N-CHANNEL ENHANCEMENT MODE POWER MOSFET DESCRIPTION The UTC UTT100N08 is an N-channel enhancement mode Power FET using UTCs advanced technology to provide customers with a minimum on-state resistance and superior switching performance. It also can withstand high energy pulse in the avalanche and commutation mode. FEATURES * Fast switching speed * RDS(ON)= 7m @ VGS=10V * Work below 175C * 100% avalanche tested * Improved dv/dt capability SYMBOL 2.Drain1.Gate3.Source ORDERING INFORMATION Ordering Number Pin Assignment Package Packing Lead Free Halogen Free 1 2 3 UTT100N08L-TA3-T UTT100N08G-TA3-T TO-220 G D S TubeNote: Pin Assignment: G: Gate D: Drain S: Source UTT100N08L-TA3-T(1)Packing Type(1) T: Tube(2)Package Type (2) TA3: TO-220(3) G: Halogen F
