   Наименование прибора: AP18N50W
   Тип транзистора: MOSFET
   Полярность: N
   Pdⓘ - Максимальная рассеиваемая мощность: 150 W
   |Vds|ⓘ - Предельно допустимое напряжение сток-исток: 500 V
   |Vgs|ⓘ - Предельно допустимое напряжение затвор-исток: 30 V
   |Vgs(th)|ⓘ - Пороговое напряжение включения: 4 V
   |Id|ⓘ - Максимально допустимый постоянный ток стока: 20 A
   Tjⓘ - Максимальная температура канала: 150 °C
   Qgⓘ - Общий заряд затвора: 94 nC
   trⓘ - Время нарастания: 80 ns
   Cossⓘ - Выходная емкость: 350 pf
   Rdsⓘ - Сопротивление сток-исток открытого транзистора: 0.27 Ohm
   Тип корпуса: TO3P

 Аналог (замена) для AP18N50W





AP18N50W Datasheet (PDF)

 ..1. Size:94K  ape
 ap18n50w.pdf

AP18N50W AP18N50W

AP18N50WRoHS-compliant ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFETD Low On-resistance BVDSS 500V Simple Drive Requirement RDS(ON) 0.27 Fast Switching Characteristic ID 20AGSDescriptionAdvanced Power MOSFETs from APEC provide the designer withthe best combination of fast switching, ruggedized device design, lowon-resistance

 9.1. Size:57K  ape
 ap18n20ags-hf.pdf

AP18N50W AP18N50W

AP18N20AGS-HFHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFETD Low Gate Charge BVDSS 200V Simple Drive Requirement RDS(ON) 170m Fast Switching Characteristic ID 18AG RoHS Compliant & Halogen-FreeSDescriptionAdvanced Power MOSFETs from APEC provide thedesigner with the best combination of fast switching,Grugge

 9.2. Size:99K  ape
 ap18n20gh-hf ap18n20gj-hf.pdf

AP18N50W AP18N50W

AP18N20GH/J-HFHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Simple Drive Requirement BVDSS 200VD Low On-resistance RDS(ON) 170m Fast Switching Characteristics ID 18A RoHS Compliant & Halogen-Free GSDescriptionAdvanced Power MOSFETs from APEC provide theGdesigner with the best combination of fast switching, D

 9.3. Size:172K  ape
 ap18n20gs.pdf

AP18N50W AP18N50W

AP18N20GS/P-HFHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFETD Low Gate Charge BVDSS 200V Simple Drive Requirement RDS(ON) 170m Fast Switching Characteristic ID 18AG RoHS Compliant & Halogen-FreeSDescriptionAP18N20 series are from Advanced Power innovated design andsilicon process technology to achieve the lowes

 9.4. Size:102K  ape
 ap18n20gp-hf ap18n20gs-hf.pdf

AP18N50W AP18N50W

AP18N20GS/P-HFHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFETD Low Gate Charge BVDSS 200V Simple Drive Requirement RDS(ON) 170m Fast Switching Characteristic ID 18AG RoHS Compliant & Halogen-FreeSDescriptionAdvanced Power MOSFETs from APEC provide thedesigner with the best combination of fast switching, GTO-22

 9.5. Size:155K  ape
 ap18n20gi.pdf

AP18N50W AP18N50W

AP18N20GIRoHS-compliant ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFETD Low Gate Charge BVDSS 200V Simple Drive Requirement RDS(ON) 170m Fast Switching Characteristic ID 18AGSDescriptionAdvanced Power MOSFETs from APEC provide the designer withthe best combination of fast switching, ruggedized device design,GDlow on-resist
