AP4955GM MOSFET - описание производителя. Даташиты. Основные параметры и характеристики. Поиск аналога. Справочник
Наименование прибора: AP4955GM
Тип транзистора: MOSFET
Полярность: P
Pdⓘ - Максимальная рассеиваемая мощность: 2 W
|Vds|ⓘ - Предельно допустимое напряжение сток-исток: 20 V
|Vgs|ⓘ - Предельно допустимое напряжение затвор-исток: 12 V
|Id|ⓘ - Максимально допустимый постоянный ток стока: 5.6 A
Tjⓘ - Максимальная температура канала: 150 °C
trⓘ - Время нарастания: 10 ns
Cossⓘ - Выходная емкость: 270 pf
Rdsⓘ - Сопротивление сток-исток открытого транзистора: 0.045 Ohm
Тип корпуса: SO8
AP4955GM Datasheet (PDF)
ap4955gm.pdf
AP4955GMRoHS-compliant ProductAdvanced Power DUAL P-CHANNEL ENHANCEMENTElectronics Corp. MODE POWER MOSFETD2 Simple Drive Requirement BVDSS -20VD2D1 Low Gate Charge RDS(ON) 45mD1 Fast Switching Characteristic ID -5.6AG2S2G1S1DescriptionAdvanced Power MOSFETs from APEC provide theD2D1designer with the best combination of fast switching,ruggedize
ap4955gm-hf.pdf
AP4955GM-HFHalogen-Free ProductAdvanced Power DUAL P-CHANNEL ENHANCEMENT Electronics Corp. MODE POWER MOSFETD2 Simple Drive Requirement BVDSS -20VD2D1 Low Gate Charge RDS(ON) 45mD1 Fast Switching Characteristic ID -5.6AG2S2 RoHS Compliant & Halogen-FreeG1S1DescriptionAdvanced Power MOSFETs from APEC provide theD2D1designer with the best comb
ap4951gm.pdf
AP4951GMRoHS-compliant ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Simple Drive Requirement BVDSS -60VD2D2D1 Low Gate Charge RDS(ON) 96mD1 Fast Switching Performance ID -3.4AG2S2G1S1SO-8DescriptionD2D1Advanced Power MOSFETs from APEC provide the designer withthe best combination of fast switching, ruggedized d
ap4957agm-hf.pdf
AP4957AGM-HFHalogen-Free ProductAdvanced Power DUAL P-CHANNEL ENHANCEMENT Electronics Corp. MODE POWER MOSFET Low On-Resistance BVDSS -30VD2D2 Simple Drive Requirement RDS(ON) 26mD1D1 Dual P MOSFET Package ID -7.4AG2S2 RoHS Compliant & Halogen-FreeG1S1SO-8DescriptionAdvanced Power MOSFETs from APEC provide theD2D1designer with the best com
ap4959gm.pdf
AP4959GMRoHS-compliant ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFETD2 Lower Turn-on Voltage BVDSS -16VD2D1 Simple Drive Requirement RDS(ON) 65mD1 Dual P MOSFET Package ID -4.7AG2S2SO-8G1S1DescriptionD2D1Advanced Power MOSFETs from APEC provide thedesigner with the best combination of fast switching,ruggedized
ap4951gm-hf.pdf
AP4951GM-HFHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Simple Drive Requirement BVDSS -60VD2D2D1 Low Gate Charge RDS(ON) 96mD1 Fast Switching Performance ID -3.4AG2S2 RoHS Compliant & Halogen-FreeG1S1SO-8DescriptionAdvanced Power MOSFETs from APEC provide the designer withD2D1the best combin
ap4957agm.pdf
AP4957AGMRoHS-compliant ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Low On-Resistance BVDSS -30VD2D2 Simple Drive Requirement RDS(ON) 26mD1D1 Dual P MOSFET Package ID -7.4AG2S2G1SO-8S1DescriptionD2D1Advanced Power MOSFETs from APEC provide thedesigner with the best combination of fast switching,ruggedized de
ap4953gm-hf.pdf
AP4953GM-HFHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Simple Drive Requirement BVDSS -30VD2D2 Low Gate Charge RDS(ON) 53mD1D1 Fast Switching ID -5AG2 RoHS CompliantS2G1SO-8S1D2Description D1Advanced Power MOSFETs from APEC provide thedesigner with the best combination of fast switching,G2G
ap4953gm.pdf
AP4953GMRoHS-compliant ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Simple Drive Requirement BVDSS -30VD2D2 Low Gate Charge RDS(ON) 53mD1D1 Fast Switching ID -5AG2S2G1SO-8S1D2Description D1Advanced Power MOSFETs from APEC provide thedesigner with the best combination of fast switching,G2G1ruggedized device
ap4957gm.pdf
AP4957GMPb Free Plating ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Low On-Resistance BVDSS -30VD2D2 Simple Drive Requirement RDS(ON) 24mD1D1 Dual P MOSFET Package ID -7.7AG2S2G1SO-8S1DescriptionD2D1The Advanced Power MOSFETs from APEC provide thedesigner with the b
ap4951gm.pdf
AP4951GMwww.VBsemi.twDual P-Channel 6 0-V (D-S) MOSFETFEATURESPRODUCT SUMMARY Halogen-freeVDS (V) RDS(on) ()ID (A)d, e Qg (Typ.) TrenchFET Power MOSFET0.059 at VGS = - 10 V - 5.3 100 % UIS TestedRoHS- 60 17 nCCOMPLIANT0.069 at VGS = - 4.5 V - 5.0APPLICATIONS Load SwitchesS1 S2SO-8S1 1 D18G1 G2G1 2 D17S2 3 D26G2 4 D25Top Vi
ap4953m.pdf
AP4953Mwww.VBsemi.twDual P-Channel 30-V (D-S) MOSFETFEATURESPRODUCT SUMMARY Halogen-freeVDS (V) RDS(on) ()ID (A)d, e Qg (Typ.) TrenchFET Power MOSFET0.029 at VGS = - 10 V - 7.3 100 % UIS TestedRoHS- 30 17 nCCOMPLIANT0.039 at VGS = - 4.5 V - 6.3APPLICATIONS Load SwitchesS1 S2SO-8S1 1 D18G1 G2G1 2 D17S2 3 D26G2 4 D25Top View
ap4953gm.pdf
AP4953GMwww.VBsemi.twDual P-Channel 30-V (D-S) MOSFETFEATURESPRODUCT SUMMARY Halogen-freeVDS (V) RDS(on) ()ID (A)d, e Qg (Typ.) TrenchFET Power MOSFET0.029 at VGS = - 10 V - 7.3 100 % UIS TestedRoHS- 30 17 nCCOMPLIANT0.039 at VGS = - 4.5 V - 6.3APPLICATIONS Load SwitchesS1 S2SO-8S1 1 D18G1 G2G1 2 D17S2 3 D26G2 4 D25Top Vie
