   Наименование прибора: AP0903GM
   Тип транзистора: MOSFET
   Полярность: N
   Pdⓘ - Максимальная рассеиваемая мощность: 2.5 W
   |Vds|ⓘ - Предельно допустимое напряжение сток-исток: 30 V
   |Vgs|ⓘ - Предельно допустимое напряжение затвор-исток: 20 V
   |Id|ⓘ - Максимально допустимый постоянный ток стока: 13.3 A
   trⓘ - Время нарастания: 5 ns
   Cossⓘ - Выходная емкость: 190 pf
   Rdsⓘ - Сопротивление сток-исток открытого транзистора: 0.0085 Ohm
   Тип корпуса: SO8

 Аналог (замена) для AP0903GM





AP0903GM Datasheet (PDF)

 ..1. Size:168K  ape
 ap0903gm.pdf

AP0903GM AP0903GM

AP0903GM-HFHalogen-Free Product Advanced Power N-CHANNEL ENHANCEMENT MODE Electronics Corp. POWER MOSFET Low On-resistance BVDSS 30VDDD Simple Drive Requirement RDS(ON) 8.5mD Fast Switching Characteristic ID 13.3AGS RoHS Compliant & Halogen-FreeSSSO-8DescriptionDAP0903 series are from

 0.1. Size:95K  ape
 ap0903gm-hf.pdf

AP0903GM AP0903GM

AP0903GM-HFHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Low On-resistance BVDSS 30VDDD Simple Drive Requirement RDS(ON) 8.5mD Fast Switching Characteristic ID 13.3AGS RoHS Compliant & Halogen-FreeSSSO-8DescriptionDAdvanced Power MOSFETs from APEC provide thedesigner with the best combination of

 7.1. Size:95K  ape
 ap0903gyt-hf.pdf

AP0903GM AP0903GM

AP0903GYT-HFHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Simple Drive Requirement D BVDSS 30V Good Thermal Dissipation RDS(ON) 9m Low On-resistance ID 16AG RoHS Compliant & Halogen-FreeSDDDDescriptionDAdvanced Power MOSFETs from APEC provide thedesigner with the best combination of fast switching,

 7.2. Size:111K  ape
 ap0903gyt.pdf

AP0903GM AP0903GM

AP0903GYT-HFHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Simple Drive Requirement D BVDSS 30V Good Thermal Dissipation RDS(ON) 9m Low On-resistance ID 16AG RoHS Compliant & Halogen-FreeSDDDDescriptionDAdvanced Power MOSFETs from APEC provide the designer withthe best combination of fast switching, rugge

 7.3. Size:94K  ape
 ap0903gh-hf.pdf

AP0903GM AP0903GM

AP0903GH-HFHalogen-Free ProductAdvanced Power N-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Low On-resistance D BVDSS 30V Simple Drive Requirement RDS(ON) 9m Fast Switching Characteristic ID 51AG RoHS Compliant & Halogen-FreeSDescriptionAdvanced Power MOSFETs from APEC provide thedesigner with the best combination of fast switching,GD
