AP80N08NF - Даташиты. Аналоги. Основные параметры
Наименование производителя: AP80N08NF
Тип транзистора: MOSFET
Полярность: N
Pd ⓘ - Максимальная рассеиваемая мощность: 56
W
|Vds|ⓘ - Предельно допустимое напряжение сток-исток: 80
V
|Vgs|ⓘ - Предельно допустимое напряжение затвор-исток: 20
V
|Id| ⓘ - Максимально
допустимый постоянный ток стока: 80
A
Tj ⓘ - Максимальная температура канала: 150
°C
tr ⓘ -
Время нарастания: 4.2
ns
Cossⓘ - Выходная емкость: 410
pf
Rds ⓘ - Сопротивление сток-исток открытого транзистора: 0.0055
Ohm
Тип корпуса:
PDFN5X6-8L
Аналог (замена) для AP80N08NF
AP80N08NF Datasheet (PDF)
..1. Size:3601K cn apm
ap80n08nf.pdf
AP80N08NF 80V N- Channel Enhancement Mode MOSFET Description The AP80N08NF uses advanced trench technology to provide excellent R , low gate charge and DS(ON) operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = 80V I =80A DS D R
7.1. Size:2412K cn apm
ap80n08d.pdf
AP80N08D 80V N-Channel Enhancement Mode MOSFET Description The AP80N08D uses advanced trench technology to provide excellent R , low gate charge and DS(ON) operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = 80V I =80A DS D R
8.3. Size:175K ape
ap80n03gp.pdf
AP80N03GS/P-HF Halogen-Free Product Advanced Power N-CHANNEL ENHANCEMENT MODE Electronics Corp. POWER MOSFET Low On-Resistance BVDSS 30V D Fast Switching Characteristic RDS(ON) 8m Simple Drive Requirement ID 80A G RoHS Compliant & Halogen-Free S Description AP80N03 series are from Advanced Power innovated design and silicon G process technology to achieve the low
8.9. Size:1395K cn apm
ap80n07f.pdf
AP80N07F 68V N-Channel Enhancement Mode MOSFET Description The AP80N07F uses advanced trench technology to provide excellent R , low gate charge and DS(ON) operation with Hight EAS. This device is suitable for use as a Battery protection or in other Switching application. General Features V = 68V I =80A DS D R
8.10. Size:1135K cn apm
ap80n02nf.pdf
AP80N02NF 20V N-Channel Enhancement Mode MOSFET Description The AP80N02NF uses advanced trench technology to provide excellent R , low gate charge and DS(ON) operation with gate voltages as low as 2.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = 20V I =80A DS D R
8.11. Size:1548K cn apm
ap80n07p ap80n07t.pdf
AP80N07PIT 68V N-Channel Enhancement Mode MOSFET Description The AP80N07P/T uses advanced trench technology to provide excellent R , low gate charge and DS(ON) operation with Hight EAS. This device is suitable for use as a Battery protection or in other Switching application. General Features V = 68V I =80A DS D R
8.12. Size:2631K cn apm
ap80n06d.pdf
AP80N06D 60V N-Channel Enhancement Mode MOSFET Description The AP80N06D uses advanced trench technology to provide excellent R , low gate charge and DS(ON) operation with gate voltages as low as 7.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = 60V I =80 A DS D R
8.13. Size:1459K cn apm
ap80n07d.pdf
AP80N07D 68V N-Channel Enhancement Mode MOSFET Description The AP80N07D uses advanced trench technology to provide excellent R , low gate charge and DS(ON) operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = 68V I =80A DS D R
8.14. Size:2440K cn apm
ap80n06nf.pdf
AP80N06NF 60V N-Channel Enhancement Mode MOSFET Description The AP80N06NF uses advanced trench technology to provide excellent R , low gate charge and DS(ON) operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = 60V I =80A DS D R
8.15. Size:1838K cn apm
ap80n03df.pdf
AP80N03DF 30V N-Channel Enhancement Mode MOSFET Description The AP80N03DF uses advanced trench technology to provide excellent R , low gate charge and DS(ON) operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = 30V I =80A DS D R
8.16. Size:1216K cn apm
ap80n03d.pdf
AP80N03D 30V N-Channel Enhancement Mode MOSFET Description The AP80N03D uses advanced trench technology to provide excellent R , low gate charge and DS(ON) operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = 30V I =80 A DS D R
8.17. Size:1407K cn apm
ap80n04df.pdf
AP80N04DF 40V N-Channel Enhancement Mode MOSFET Description The AP80N04DF uses advanced trench technology to provide excellent R , low gate charge and DS(ON) operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = 40V I =80 A DS D R
8.18. Size:2217K cn apm
ap80n02df.pdf
AP80N02DF 20V N-Channel Enhancement Mode MOSFET Description The AP80N02DF uses advanced trench technology to provide excellent R , low gate charge and DS(ON) operation with gate voltages as low as 2.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = 20V I =80 A DS D R
8.19. Size:1583K cn apm
ap80n03nf.pdf
AP80N03NF 30V N-Channel Enhancement Mode MOSFET Description The AP80N03NF uses advanced trench technology to provide excellent R , low gate charge and DS(ON) operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = 30V I =80A DS D R
8.20. Size:1651K cn apm
ap80n04d.pdf
AP80N04D 40V N-Channel Enhancement Mode MOSFET Description The AP80N04D uses advanced trench technology to provide excellent R , low gate charge and DS(ON) operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = 40V I =80 A DS D R
