MPS6566 - описание и поиск аналогов

MOTOROLA Order this document SEMICONDUCTOR TECHNICAL DATA by MPS6560/D Audio Transistor MPS6560 NPN Silicon COLLECTOR 3 2 BASE 1 2 1 3 EMITTER CASE 29 04, STYLE 1 MAXIMUM RATINGS TO 92 (TO 226AA) Rating Symbol Value Unit Collector Emitter Voltage VCEO 25 Vdc Collector Base Voltage VCBO 25 Vdc Emitter Base Voltage VEBO 5.0 Vdc Collector Current Continuous I

Discrete POWER & Signal Technologies MPS6562 C TO-92 B E PNP General Purpose Amplifier This device is designed for use as general purpose amplifiers and switches requiring collector currents to 500 mA. Sourced from Process 67. See TN4033A for characteristics. Absolute Maximum Ratings* TA = 25 C unless otherwise noted Symbol Parameter Value Units VCEO Collector-Emitter Voltage 25 V

MPS6560 Audio Transistor NPN Silicon Features Pb-Free Package is Available* http //onsemi.com COLLECTOR MAXIMUM RATINGS 3 Rating Symbol Value Unit Collector -Emitter Voltage VCEO 25 Vdc 2 BASE Collector -Base Voltage VCBO 25 Vdc Emitter -Base Voltage VEBO 5.0 Vdc 1 Collector Current - Continuous IC 500 mAdc EMITTER Total Device Dissipation @ TA = 25 C PD 625 W Derate abo

Continental Device India Limited An ISO/TS 16949, ISO 9001 and ISO 14001 Certified Company SILICON PLANAR EPITAXIAL TRANSISTORS MPS6560 NPN MPS6562 PNP TO-92 Plastic Package C B E AudioTransistors ABSOLUTE MAXIMUM RATINGS DESCRIPTION SYMBOL VALUE UNITS VCBO Collector Base Voltage 25 V VCEO Collector Emitter Voltage 25 V VEBO Emitter Base Voltage 5.0 V IC Collector Current Con
