H1116 Datasheet and Replacement


   Type Designator: H1116
   Material of Transistor: Si
   Polarity: PNP
   Maximum Collector Power Dissipation (Pc): 0.75 W
   Maximum Collector-Base Voltage |Vcb|: 60 V
   Maximum Collector-Emitter Voltage |Vce|: 50 V
   Maximum Emitter-Base Voltage |Veb|: 6 V
   Maximum Collector Current |Ic max|: 1 A
   Max. Operating Junction Temperature (Tj): 150 °C
   Transition Frequency (ft): 70 MHz
   Collector Capacitance (Cc): 25 pF
   Forward Current Transfer Ratio (hFE), MIN: 135
   Noise Figure, dB: -
   Package: TO92


 H1116 Substitution

   - BJT ⓘ Cross-Reference Search



H1116 Datasheet (PDF)

 ..1. Size:106K  shantou-huashan
 h1116.pdf pdf_icon

H1116

PNP S I L I C O N T R A N S I S T O R Shantou Huashan Electronic Devices Co.,Ltd. H1116 APPLICATIONS Audio frequency power Aamplifier& Medium Speed switching Low frequency power amplifier. ABSOLUTE MAXIMUM RATINGSTa=25 TO-92 TstgStorage Temperature -55~150 TjJunction Temperature
