HS733 Datasheet and Replacement


   Type Designator: HS733
   Material of Transistor: Si
   Polarity: PNP
   Maximum Collector Power Dissipation (Pc): 0.25 W
   Maximum Collector-Base Voltage |Vcb|: 60 V
   Maximum Collector-Emitter Voltage |Vce|: 50 V
   Maximum Emitter-Base Voltage |Veb|: 5 V
   Maximum Collector Current |Ic max|: 0.15 A
   Max. Operating Junction Temperature (Tj): 150 °C
   Transition Frequency (ft): 50 MHz
   Collector Capacitance (Cc): 2.8 pF
   Forward Current Transfer Ratio (hFE), MIN: 70
   Noise Figure, dB: -
   Package: TO92


 HS733 Substitution

   - BJT ⓘ Cross-Reference Search



HS733 Datasheet (PDF)

 ..1. Size:261K  shantou-huashan
 hs733.pdf pdf_icon

HS733

PNP S I L I C O N T R A N S I S T O R Shantou Huashan Electronic Devices Co.,Ltd. HS733 APPLICATIONS The H733 is designed for driver stage of AF amplifier And low speed switching. ABSOLUTE MAXIMUM RATINGSTa=25 TO-92 TstgStorage Temperature -55~150 TjJunction Temperature150
