View 2n3235 datasheet:

Inchange Semiconductor Product Specification Silicon NPN Power Transistors 2N3235 DESCRIPTION With TO-3 package Excellent safe operating area Low collector saturation voltage APPLICATIONS Designed for generalpurpose switching and amplifier applications. PINNING PIN DESCRIPTION1 Base 2 EmitterFig.1 simplified outline (TO-3) and symbol 3 CollectorABSOLUTE MAXIMUM RATINGS(Ta=25) SYMBOL PARAMETER CONDITIONS VALUE UNITVCBO Collector-base voltage Open emitter 65 V VCEO Collector-emitter voltage Open base 55 V VEBO Emitter-base voltage Open collector 7 V IC Collector current 15 A IB Base current 7 A PC Collector power dissipation TC=25 115 W Tj Junction temperature 150 Storage temperature -65~200 Tstg THERMAL CHARACTERISTICS SYMBOL PARAMETER VALUE UNITThermal resistance junction to case 1.52 /W R(th) jc
