View 2sd882-r 2sd882-q 2sd882-p 2sd882-e datasheet:

D882NPN Transistors Features3 NPN transistor High current output up to 3A2 Low Saturation Voltage Complement to 2SB772 1.Base12.Collector3.Emitter Simplified outline(SOT-89)Absolute Maximum Ratings Ta = 25Parameter Symbol Rating UnitCollector to Base Voltage VCBO 40 VCollector to Emitter Voltage VCEO 30 VEmitter to Base Voltage VEBO 6 VCollector Current to Continuous IC 3 ACollector Dissipation Pc 0.5 WJunction Temperature TJ 150Storage Temperature Tstg -55 to 150Electrical Characteristics Ta = 25Parameter Symbol Testconditions Min Typ Max UnitCollector-base breakdown voltage VCBO Ic=100uA ,IE=0 40 VCollector-emitter breakdown voltage VCEO IC= 10 mA , IB=0 30 VEmitter-base breakdown voltage VEBO IE= 100 uA ,IC=0 6 VCollector cut-off current ICBO VCB=40 V , IE=0 1 uACollector cut-off current ICEO VCE=30 V , IB=0 10 uA
