2n6796.pdf datasheet:
2N6796MECHANICAL DATADimensions in mm (inches)TMOS FET TRANSISTOR N CHANNEL FEATURES VDSS = 100V ID = 8A ! RDSON = 0.18 TO39 METAL PACKAGEUnderside ViewPIN 1 Source PIN 2 Gate PIN 3 Drain CaseABSOLUTE MAXIMUM RATINGS (Tcase = 25C unless otherwise stated)VDSS DrainSource Voltage100VVDGR DrainGate Voltage (RGS = 1.0m)100VVGS GateSource Voltage20VID Drain Current Continuous8.0AIDM Drain Current Pulsed32APD Total Device Dissipation @ TC = 25C25WDerate above 25C0.2W/ CWTJ , TSTG Operating and Storage Junction Temperature Range55
