tip120 tip121 tip122 tip125 tip126 tip127.pdf datasheet:

tip120_tip121_tip122_tip125_tip126_tip127tip120_tip121_tip122_tip125_tip126_tip127

JIANGSU CHANGJIANG ELECTRONICS TECHNOLOGY CO., LTD TO-126 Plastic-Encapsulate Transistors TIP120,121,122 Darlington Transistor (NPN) TO-126 TIP125,126,127 Darlington Transistor (PNP) 1.EMITTER 2.COLLECTOR FEATURES 3.BASEMedium Power Complementary Silicon Transistors MAXIMUM RATINGS (Ta=25 unless otherwise noted) Symbol Parameter TIP120 TIP121 TIP122 Unit TIP125 TIP126 TIP127 VCBO Collector-Base Voltage 60 80 100 VVCEO Collector-Emitter Voltage 60 80 100 VVEBO Emitter-Base Voltage 5 VIC Collector Current -Continuous 5 A PC * Collector Power Dissipation 1.25 W RJA Thermal Resistance Junction to Ambient 100 /W /W RJc Thermal Resistance Junction to Case 8.33 TJ Junction Temperature 150 Tstg Storage Temperature -55~+150 ELECTRICAL CHARACTERISTICS (Ta=25 unless otherwise specified) Parameter Symbol Test conditions Mi
