TK50P04M1 MOSFET. Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características

   Número de Parte: TK50P04M1
   Tipo de FET: MOSFET
   Polaridad de transistor: N

ESPECIFICACIONES MÁXIMAS

   Pdⓘ - Máxima disipación de potencia: 60 W
   |Vds|ⓘ - Voltaje máximo drenador - fuente: 40 V
   |Vgs|ⓘ - Voltaje máximo fuente - puerta: 20 V
   |Id|ⓘ - Corriente continua de drenaje: 50 A
   Tjⓘ - Temperatura máxima de unión: 150 °C

CARACTERÍSTICAS ELÉCTRICAS

   trⓘ - Tiempo de subida: 22 nS
   Cossⓘ - Capacitancia de salida: 420 pF
   Rds(on)ⓘ - Resistencia estado encendido drenaje a fuente: 0.0087 Ohm
   Paquete / Cubierta: DPAK

Búsqueda de reemplazo de MOSFET TK50P04M1

TK50P04M1 Datasheet (PDF)

..1. Size:238K toshiba
tk50p04m1.pdf

TK50P04M1MOSFETs Silicon N-Channel MOS (U-MOS-H)TK50P04M1TK50P04M1TK50P04M1TK50P04M11. Applications1. Applications1. Applications1. Applications Switching Voltage Regulators Motor Drivers2. Features2. Features2. Features2. Features(1) High-speed switching(2) Low gate charge: QSW = 9.4 nC (typ.)(3) Low drain-source on-resistance: RDS(ON) = 6.7 m (t

8.1. Size:242K toshiba
tk50p03m1.pdf

TK50P03M1MOSFETs Silicon N-Channel MOS (U-MOS-H)TK50P03M1TK50P03M1TK50P03M1TK50P03M11. Applications1. Applications1. Applications1. Applications DC-DC Converters Desktop PCs2. Features2. Features2. Features2. Features(1) High-speed switching(2) Low gate charge: QSW = 8.2 nC (typ.)(3) Low drain-source on-resistance: RDS(ON) = 5.8 m (typ.) (VGS = 10

8.2. Size:696K first silicon
ftk50p03pdfn56.pdf

SEMICONDUCTORFTK50P03PDFN56TECHNICAL DATAP-Channel Power MOSFETPDFN56-8L DESCRIPTION The FTK50P03PDFN56 uses advanced trench technology and design to provide excellent RDS(ON) with low gate charge. It can be used in a wide variety of applications FEATURES High density cell design for ultra low RDS(ON) Excellent package for good heat dissipation Fully characte
