2N65K MOSFET. Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características

   Número de Parte: 2N65K
   Tipo de FET: MOSFET
   Polaridad de transistor: N

ESPECIFICACIONES MÁXIMAS

   Pdⓘ - Máxima disipación de potencia: 28 W
   |Vds|ⓘ - Voltaje máximo drenador - fuente: 650 V
   |Vgs|ⓘ - Voltaje máximo fuente - puerta: 30 V
   |Id|ⓘ - Corriente continua de drenaje: 2 A
   Tjⓘ - Temperatura máxima de unión: 150 °C

CARACTERÍSTICAS ELÉCTRICAS

   |Vgs(th)|ⓘ - Tensión umbral entre puerta y fuente: 5 V
   Qgⓘ - Carga de la puerta: 9 nC
   trⓘ - Tiempo de subida: 25 nS
   Cossⓘ - Capacitancia de salida: 40 pF
   Rds(on)ⓘ - Resistencia estado encendido drenaje a fuente: 3.9 Ohm
   Paquete / Cubierta: TO-252

Búsqueda de reemplazo de MOSFET 2N65K

2N65K Datasheet (PDF)

..1. Size:229K utc
2n65k.pdf

UNISONIC TECHNOLOGIES CO., LTD 2N65K Power MOSFET 2A, 650V N-CHANNEL POWER MOSFET DESCRIPTION The UTC 2N65K is a high voltage power MOSFET and is designed to have better characteristics, such as fast switching time, low gate charge, low on-state resistance and have a high rugged avalanche characteristics. This power MOSFET is usually used at high speed switching applicatio

0.1. Size:298K 1
12n65kl-t 12n65kg-t.pdf

UNISONIC TECHNOLOGIES CO., LTD 12N65K-MT Power MOSFET 12A, 650V N-CHANNEL POWER MOSFET DESCRIPTION The UTC 12N65K-MT are N-Channel enhancement mode power field effect transistors (MOSFET) which are produced byusing UTCs proprietary, planar stripe and DMOS technology. These devices are suited for high efficiency switch mode power supply. To minimize on-state resistance,

0.2. Size:243K utc
2n65kl-tm3-t 2n65kg-tm3-t 2n65kl-tms-t 2n65kg-tms-t 2n65kl-tms2-t 2n65kg-tms2-t 2n65kl-tms4-t 2n65kg-tms4-t 2n65kl-tn3-r 2n65kg-tn3-r 2n65kl-tnd-r.pdf

UNISONIC TECHNOLOGIES CO., LTD 2N65K-MT Power MOSFET 2A, 650V N-CHANNEL POWER MOSFET DESCRIPTION The UTC 2N65K-MT is a high voltage power MOSFET and is designed to have better characteristics, such as fast switching time, low gate charge, low on-state resistance and have a high rugged avalanche characteristics. This power MOSFET is usually used at high speed switching appl

0.3. Size:243K utc
2n65kl-ta3-t 2n65kg-ta3-t 2n65kl-tf3-t 2n65kg-tf3-t 2n65kl-tf1-t 2n65kg-tf1-t 2n65kl-tf2-t 2n65kg-tf2-t 2n65kl-tf3t-t 2n65kg-tf3t-t 2n65kg-tnd-r.pdf

0.4. Size:298K utc
12n65kl-ta3-t 12n65kg-ta3-t 12n65kl-tf1-t 12n65kg-tf1-t 12n65kl-tf2-t 12n65kg-tf2-t 12n65kl-tf3-t 12n65kg-tf3-t 12n65kl-tq2-t 12n65kg-tq2-t 12n65kl-tq2-r 12n65kg-tq2-r.pdf

0.5. Size:394K silan
svf12n65f svf12n65k svf12n65s svf12n65str.pdf

SVF12N65F/K/S 12A650V N 2SVF12N65F/K/S N MOS F-CellTM VDMOS 113 TO-263-2L3

0.6. Size:688K samwin
swn2n65k swd2n65k.pdf

SW2N65K N-channel Enhanced mode TO-251N/TO-252 MOSFET Features BVDSS : 650V TO-252 TO-251N ID : 2A High ruggedness Low RDS(ON) (Typ 1.9)@VGS=10V RDS(ON) : 1.9 Low Gate Charge (Typ 7.8nC) 2 Improved dv/dt Capability 100% Avalanche Tested 1 1 2 2 Application:Power Supply,LED Boost 1 3 3 3 1. Gate 2. Drain 3. Source General Descrip
