2N60 MOSFET Equivalente. Reemplazo. Hoja de especificaciones. Principales características
Número de Parte: 2N60
Tipo de FET: MOSFET
Polaridad de transistor: N
ESPECIFICACIONES MÁXIMAS
Pdⓘ - Máxima disipación de potencia: 54 W
|Vds|ⓘ - Voltaje máximo drenador-fuente: 600 V
|Vgs|ⓘ - Voltaje máximo fuente-puerta: 30 V
|Id|ⓘ - Corriente continua de drenaje: 2 A
Tjⓘ - Temperatura máxima de unión: 150 °C
CARACTERÍSTICAS ELÉCTRICAS
trⓘ - Tiempo de subida: 35 nS
Cossⓘ - Capacitancia de salida: 45 pF
RDSonⓘ - Resistencia estado encendido drenaje a fuente: 3.6 Ohm
Encapsulados: TO-262 TO-251 TO-252 TO-220 TO-220F TO-126 DFN-8
Búsqueda de reemplazo de 2N60 MOSFET
- Selecciónⓘ de transistores por parámetros
2N60 datasheet
2n60.pdf
UNISONIC TECHNOLOGIES CO., LTD 2N60 Power MOSFET 2A, 600V N-CHANNEL POWER MOSFET DESCRIPTION The UTC 2N60 is a high voltage power MOSFET and is designed to have better characteristics, such as fast switching time, low gate charge, low on-state resistance and have a high rugged avalanche characteristics. This power MOSFET is usually used at high speed switching applications
2n60.pdf
R UMW UMW 2N60 UMW 2N60 N- MOS N- MOS N- MOS N- MOS Tc=25 C Tc=25 C Tc=25 C Tc=25 C Absolute Maximum Ratings Tc=25 C Absolute Maximum Ratings Tc=25 C Absolute Maximum Ratings Tc=25 C TO-220/220F/251T/252/223 Absolute Maximum Ratings Tc=25 C PARAMETER SYMBOL VALUE UNIT PARAMETER SYMBOL VALUE
2n60 .pdf
isc N-Channel MOSFET Transistor 2N60 FEATURES Drain Current I = 2A@ T =25 D C Drain Source Voltage- V = 600V(Min) DSS Static Drain-Source On-Resistance R = 5.0 (Max) DS(on) 100% avalanche tested Minimum Lot-to-Lot variations for robust device performance and reliable operation APPLICATIONS Switching power supplies,converters,AC and DC motor controls ABSO
2n60.pdf
isc N-Channel MOSFET Transistor 2N60 FEATURES Drain Current I = 2A@ T =25 D C Drain Source Voltage- V = 600V(Min) DSS Static Drain-Source On-Resistance R = 5.0 (Max) DS(on) 100% avalanche tested Minimum Lot-to-Lot variations for robust device performance and reliable operation APPLICATIONS Switching power supplies,converters,AC and DC motor controls ABSO
