2N7006 Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características
Número de Parte: 2N7006 📄📄
Tipo de FET: MOSFET
Polaridad de transistor: N
ESPECIFICACIONES MÁXIMAS
Pdⓘ - Máxima disipación de potencia: 1 W
|Vds|ⓘ - Voltaje máximo drenador-fuente: 350 V
|Vgs|ⓘ - Voltaje máximo fuente-puerta: 40 V
|Id|ⓘ - Corriente continua de drenaje: 0.32 A
Tjⓘ - Temperatura máxima de unión: 150 °C
CARACTERÍSTICAS ELÉCTRICAS
Cossⓘ - Capacitancia de salida: 220 pF
RDSonⓘ - Resistencia estado encendido drenaje a fuente: 5 Ohm
Encapsulados: TO250
📄📄 Copiar
Búsqueda de reemplazo de 2N7006 MOSFET
