640 MOSFET Equivalente. Reemplazo. Hoja de especificaciones. Principales características
Número de Parte: 640
Tipo de FET: MOSFET
Polaridad de transistor: N
ESPECIFICACIONES MÁXIMAS
Pdⓘ - Máxima disipación de potencia: 139 W
|Vds|ⓘ - Voltaje máximo drenador-fuente: 200 V
|Vgs|ⓘ - Voltaje máximo fuente-puerta: 30 V
|Id|ⓘ - Corriente continua de drenaje: 18 A
Tjⓘ - Temperatura máxima de unión: 150 °C
CARACTERÍSTICAS ELÉCTRICAS
trⓘ - Tiempo de subida: 150 nS
Cossⓘ - Capacitancia de salida: 190 pF
RDSonⓘ - Resistencia estado encendido drenaje a fuente: 0.18 Ohm
Encapsulados: TO220
Búsqueda de reemplazo de 640 MOSFET
- Selecciónⓘ de transistores por parámetros
640 datasheet
640.pdf
GOFORD 640 200V N-Channel MOSFET GENERAL DESCRIPTION VDSS RDS(ON) ID This Power MOSFET is produced using advanced planar stripe DMOS 200V 0.18 18A technology.This advanced technology has been especially tailored to minimize on-state resistance, provide superior switching performance, and withstand high energy pulse in the avalanche and commutation mode. These devices are well sui
640 f640 i640 e640 b640 d640.pdf
640/F640/I640/E640/B640/D640 18A 200V N-channel Enhancement Mode Power MOSFET 1 Description These N-channel enhanced vdmosfets, is obtained by the 2 D V = 200V self-aligned planar technology which reduce the DSS conduction loss, improve switching performance and R = 0.12 DS(on) (TYP) G enhance the avalanche energy. Which accords with the 1 RoHS standard. I = 18A 3 S D 2 Featur
