AP6P090M MOSFET. Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características

   Número de Parte: AP6P090M
   Tipo de FET: MOSFET
   Polaridad de transistor: P

ESPECIFICACIONES MÁXIMAS

   Pdⓘ - Máxima disipación de potencia: 2.5 W
   |Vds|ⓘ - Voltaje máximo drenador - fuente: 60 V
   |Vgs|ⓘ - Voltaje máximo fuente - puerta: 20 V
   |Id|ⓘ - Corriente continua de drenaje: 4 A

CARACTERÍSTICAS ELÉCTRICAS

   |Vgs(th)|ⓘ - Tensión umbral entre puerta y fuente: 3 V
   Qgⓘ - Carga de la puerta: 33 nC
   trⓘ - Tiempo de subida: 5 nS
   Cossⓘ - Capacitancia de salida: 110 pF
   Rds(on)ⓘ - Resistencia estado encendido drenaje a fuente: 0.09 Ohm
   Paquete / Cubierta: SO8

Búsqueda de reemplazo de MOSFET AP6P090M

AP6P090M Datasheet (PDF)

..1. Size:186K ape
ap6p090m.pdf

AP6P090MHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test D BVDSS -60V Simple Drive Requirement RDS(ON) 90m Fast Switching Characteristic ID3 -4AG RoHS Compliant & Halogen-FreeSDescriptionDDAP6P090 series are from Advanced Power innovated design and siliconDDprocess technology to achieve t

7.1. Size:204K ape
ap6p090h.pdf

AP6P090HHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test D BVDSS -60V Simple Drive Requirement RDS(ON) 90m Fast Switching Characteristic ID -15AG RoHS Compliant & Halogen-FreeSDescriptionAP6P090 series are from Advanced Power innovated design and GDSsilicon process technology to achieve the l

7.2. Size:169K ape
ap6p090j.pdf

AP6P090JHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test D BVDSS -60V Simple Drive Requirement RDS(ON) 90m Fast Switching Characteristic ID -15AG RoHS Compliant & Halogen-FreeSDescriptionAP6P090 series are from Advanced Power innovated design andGDsilicon process technology to achieve the low

9.1. Size:181K ape
ap6p064i.pdf

AP6P064IHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test D BVDSS -60V Simple Drive Requirement RDS(ON) 64m Fast Switching Characteristic ID4 -17AG RoHS Compliant & Halogen-FreeSDescriptionAP6P064 series are from Advanced Power innovated design andsilicon process technology to achieve the lowest p

9.2. Size:168K ape
ap6p064j.pdf

AP6P064JHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test D BVDSS -60V Simple Drive Requirement RDS(ON) 64m Fast Switching Characteristic ID -17AG RoHS Compliant & Halogen-FreeSDescriptionAP6P064 series are from Advanced Power innovated design andGDsilicon process technology to achieve the low

9.3. Size:182K ape
ap6p070i.pdf

AP6P070IHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test D BVDSS -60V Simple Drive Requirement RDS(ON) 70m Fast Switching Characteristic ID4 -16AG RoHS Compliant & Halogen-FreeSDescriptionAP6P070 series are from Advanced Power innovated design andsilicon process technology to achieve the lowest p

9.4. Size:204K ape
ap6p064h.pdf

AP6P064HHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test D BVDSS -60V Simple Drive Requirement RDS(ON) 64m Fast Switching Characteristic ID -17AG RoHS Compliant & Halogen-FreeSDescriptionAP6P064 series are from Advanced Power innovated design and GDSsilicon process technology to achieve the l

9.5. Size:205K ape
ap6p070h.pdf

AP6P070HHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test D BVDSS -60V Simple Drive Requirement RDS(ON) 70m Fast Switching Characteristic ID -16AG RoHS Compliant & Halogen-FreeSDescriptionAP6P070 series are from Advanced Power innovated design and GDSsilicon process technology to achieve the l

9.6. Size:165K ape
ap6p070p.pdf

AP6P070PHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test D BVDSS -60V Simple Drive Requirement RDS(ON) 70m Fast Switching Characteristic ID -16AG RoHS Compliant & Halogen-FreeSDescriptionAP6P070 series are from Advanced Power innovated design andsilicon process technology to achieve the lowest po

9.7. Size:67K ape
ap6p025m.pdf

AP6P025MHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test D BVDSS -60V Simple Drive Requirement RDS(ON) 25m Fast Switching Characteristic ID3 -7.3AG RoHS Compliant & Halogen-FreeSDescriptionDDAP6P025 series are from Advanced Power innovated design and siliconDDprocess technology to achieve

9.8. Size:204K ape
ap6p025h.pdf

AP6P025HHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test D BVDSS -60V Simple Drive Requirement RDS(ON) 25m Fast Switching Characteristic ID -40AG RoHS Compliant & Halogen-FreeSDescriptionAP6P025 series are from Advanced Power innovated design andGDsilicon process technology to achieve the low

9.9. Size:177K ape
ap6p025s.pdf

AP6P025SHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test D BVDSS -60V Simple Drive Requirement RDS(ON) 25m Fast Switching Characteristic ID -40AG RoHS Compliant & Halogen-FreeSDescriptionAP6P025 series are from Advanced Power innovated design andsilicon process technology to achieve the lowest po

9.10. Size:165K ape
ap6p025p.pdf

AP6P025PHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test D BVDSS -60V Simple Drive Requirement RDS(ON) 25m Fast Switching Characteristic ID -40AG RoHS Compliant & Halogen-FreeSDescriptionAP6P025 series are from Advanced Power innovated design andsilicon process technology to achieve the lowest po

9.11. Size:144K ape
ap6p064jb.pdf

AP6P064JBHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test D BVDSS -60V Simple Drive Requirement RDS(ON) 64m Fast Switching Characteristic ID -17AG RoHS Compliant & Halogen-FreeSDescriptionAP6P064 series are from Advanced Power innovated design andsilicon process technology to achieve the lowest p

9.12. Size:71K ape
ap6p070s.pdf

AP6P070SHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test D BVDSS -60V Simple Drive Requirement RDS(ON) 70m Fast Switching Characteristic ID -16AG RoHS Compliant & Halogen-FreeSDescriptionAP6P070 series are from Advanced Power innovated design andsilicon process technology to achieve the lowest po

9.13. Size:182K ape
ap6p025i.pdf

AP6P025IHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test D BVDSS -60V Simple Drive Requirement RDS(ON) 25m Fast Switching Characteristic ID -26.8AG RoHS Compliant & Halogen-FreeSDescriptionAP6P025 series are from Advanced Power innovated design andsilicon process technology to achieve the lowest
