AP2301AGN MOSFET. Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características

   Número de Parte: AP2301AGN
   Tipo de FET: MOSFET
   Polaridad de transistor: P

ESPECIFICACIONES MÁXIMAS

   Pdⓘ - Máxima disipación de potencia: 1.38 W
   |Vds|ⓘ - Voltaje máximo drenador - fuente: 20 V
   |Vgs|ⓘ - Voltaje máximo fuente - puerta: 8 V
   |Id|ⓘ - Corriente continua de drenaje: 3.3 A
   Tjⓘ - Temperatura máxima de unión: 150 °C

CARACTERÍSTICAS ELÉCTRICAS

   trⓘ - Tiempo de subida: 17 nS
   Cossⓘ - Capacitancia de salida: 90 pF
   Rds(on)ⓘ - Resistencia estado encendido drenaje a fuente: 0.097 Ohm
   Paquete / Cubierta: SOT23

Búsqueda de reemplazo de MOSFET AP2301AGN

AP2301AGN Datasheet (PDF)

..1. Size:93K ape
ap2301agn.pdf

AP2301AGNRoHS-compliant ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Simple Drive Requirement BVDSS -20V Small Package Outline RDS(ON) 97mD Surface Mount Device ID - 3.3ASSOT-23GDescriptionDAdvanced Power MOSFETs from APEC provide thedesigner with the best combination of fast switching,Glow on-resistance and cost-effec

0.1. Size:56K ape
ap2301agn-hf.pdf

AP2301AGN-HFHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Simple Drive Requirement BVDSS -20VD Small Package Outline RDS(ON) 97m Surface Mount Device ID - 3.3AS RoHS Compliant & Halogen-FreeSOT-23GDDescriptionAdvanced Power MOSFETs from APEC provide the designer with the bestcombination of fast switching,l

8.1. Size:93K ape
ap2301gn.pdf

AP2301GNRoHS-compliant ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Simple Drive Requirement BVDSS -20V Small Package Outline RDS(ON) 130mD Surface Mount Device ID - 2.6ASSOT-23GDescriptionDAdvanced Power MOSFETs from APEC provide thedesigner with the best combination of fast switching,Glow on-resistance and cost-effec

8.2. Size:96K ape
ap2301en-hf.pdf

AP2301EN-HFHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Capable of 2.5V Gate Drive BVDSS -20VD Small Package Outline RDS(ON) 130m Surface Mount Device ID -2.3AS RoHS Compliant & Halogen-FreeSOT-23SGDDescriptionAdvanced Power MOSFETs from APEC provide the designer with the bestGcombination of fast switch

8.3. Size:93K ape
ap2301bgn-hf.pdf

AP2301BGN-HFHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Simple Drive Requirement BVDSS -20V Small Package Outline RDS(ON) 130mD Surface Mount Device ID - 2.8A RoHS Compliant & Halogen-FreeSSOT-23GDescriptionDAdvanced Power MOSFETs from APEC provide thedesigner with the best combination of fast switching,

8.4. Size:97K ape
ap2301gn-hf.pdf

AP2301GN-HFHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Simple Drive Requirement BVDSS -20V Small Package Outline RDS(ON) 130mD Surface Mount Device ID - 2.6A RoHS CompliantSSOT-23GDescriptionDAdvanced Power MOSFETs from APEC provide thedesigner with the best combination of fast switching,Glow on-resi

8.5. Size:59K ape
ap2301n-hf.pdf

AP2301N-HFHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Capable of 2.5V Gate Drive BVDSS -20VD Small Package Outline RDS(ON) 130m Surface Mount Device ID -2.3AS RoHS Compliant & Halogen-FreeSOT-23SGDDescriptionAdvanced Power MOSFETs from APEC provide the designer with the bestGcombination of fast switchi

8.6. Size:150K ape
ap2301en.pdf

8.7. Size:1595K allpower
ap2301.pdf

2301 P-Channel 20-V(D-S) MOSFET DATA SHEET DESCRIPTION DThe 2301 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with gate Gvoltages as low as 2.5V. This device is suitable for use as a load switch or in PWM applications. SGENERAL FEATURES Schematic diagram VDSS RDS(ON) RDS(ON) ID(Typ) @-2.5V @-4.5V (Typ)-20V64m

8.8. Size:868K cn vbsemi
ap2301n.pdf

AP2301Nwww.VBsemi.twP-Channel 20-V (D-S) MOSFETFEATURESMOSFET PRODUCT SUMMARY Halogen-free According to IEC 61249-2-21VDS (V) RDS(on) ()ID (A)a Qg (Typ.)Definition0.035 at VGS = - 10 V - 5e TrenchFET Power MOSFETe- 20 0.043 at VGS = - 4.5 V - 5 10 nC 100 % Rg Tested0.061 at VGS = - 2.5 V - 4.8 Compliant to RoHS Directive 2002/95/ECAPPLICATIONS
