SRC60R090B MOSFET. Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características
Número de Parte: SRC60R090B
Tipo de FET: MOSFET
Polaridad de transistor: N
ESPECIFICACIONES MÁXIMAS
Pdⓘ - Máxima disipación de potencia: 300 W|Vds|ⓘ - Voltaje máximo drenador - fuente: 600 V
|Vgs|ⓘ - Voltaje máximo fuente - puerta: 30 V
|Id|ⓘ - Corriente continua de drenaje: 39.5 A
Tjⓘ - Temperatura máxima de unión: 150 °C
CARACTERÍSTICAS ELÉCTRICAS
trⓘ - Tiempo de subida: 38 nS
Cossⓘ - Capacitancia de salida: 136 pF
Rds(on)ⓘ - Resistencia estado encendido drenaje a fuente: 0.09 Ohm
Paquete / Cubierta: TO247 TO220F
Búsqueda de reemplazo de MOSFET SRC60R090B
SRC60R090B Datasheet (PDF)
src60r090b.pdf
Datasheet 90m, 600V, Super Junction N-Channel Power MOSFET SRC60R090B General Description Symbol The Sanrise SRC60R090B is a high voltage power MOSFET, fabricated using advanced super junction technology. The resulting device has extremely low on resistance, low gate charge and fast switching time, making it especially suitable for applications which require superior power
