AP80P06NF Todos los transistores



AP80P06NF MOSFET. Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características


   Número de Parte: AP80P06NF
   Tipo de FET: MOSFET
   Polaridad de transistor: P

ESPECIFICACIONES MÁXIMAS

   Pdⓘ - Máxima disipación de potencia: 104 W
   |Vds|ⓘ - Voltaje máximo drenador - fuente: 60 V
   |Vgs|ⓘ - Voltaje máximo fuente - puerta: 20 V
   |Id|ⓘ - Corriente continua de drenaje: 80 A
   Tjⓘ - Temperatura máxima de unión: 150 °C

CARACTERÍSTICAS ELÉCTRICAS


   trⓘ - Tiempo de subida: 2.5 nS
   Cossⓘ - Capacitancia de salida: 600 pF
   Rds(on)ⓘ - Resistencia estado encendido drenaje a fuente: 0.016 Ohm
   Paquete / Cubierta: PDFN5X6-8L


 Búsqueda de reemplazo de AP80P06NF MOSFET

   - Selección ⓘ de transistores por parámetros



AP80P06NF Datasheet (PDF)

 ..1. Size:1789K  cn apm
 ap80p06nf.pdf pdf_icon

AP80P06NF

AP80P06NF -60V P-Channel Enhancement Mode MOSFET Description The AP80P06NF uses advanced trench technology to provide excellent R , low gate charge and DS(ON)operation with gate voltages as low as 6V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = -60V I =-80A DS DR

 7.1. Size:1641K  cn apm
 ap80p06d.pdf pdf_icon

AP80P06NF

AP80P06D -60V P-Channel Enhancement Mode MOSFET Description The AP80P06D uses advanced trench technology to provide excellent R , low gate charge and DS(ON)operation with gate voltages as low as 6V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = -60V I =-80A DS DR

 7.2. Size:1715K  cn apm
 ap80p06p ap80p06t.pdf pdf_icon

AP80P06NF

AP80P06PIT -60V P-Channel Enhancement Mode MOSFET Description The AP80P06P/T uses advanced trench technology to provide excellent R , low gate charge and DS(ON)operation with gate voltages as low as 6V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = -60V I =-82A DS DR

 8.1. Size:1788K  cn apm
 ap80p04d.pdf pdf_icon

AP80P06NF

AP80P04D -40V P-Channel Enhancement Mode MOSFET Description The AP80P04D uses advanced trench technology to provide excellent R , low gate charge and DS(ON)operation with gate voltages as low as 4.5V. This device is suitable for use as a Battery protection or in other Switching application. General Features V = -40V I =-80 A DS DR

MOSTRAR MÁS
