P30 Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características
Número de Parte: P30 📄📄
Material: Ge
Polaridad de transistor: PNP
ESPECIFICACIONES MÁXIMAS
Disipación total del dispositivo (Pc): 0.03 W
Tensión colector-base (Vcb): 12 V
Corriente del colector DC máxima (Ic): 0.1 A
Temperatura operativa máxima (Tj): 75 °C
CARACTERÍSTICAS ELÉCTRICAS
Transición de frecuencia (fT): 10 MHz
Capacitancia de salida (Cc): 6 pF
Ganancia de corriente contínua (hFE): 80
