TP3405
. Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características
Número de Parte: TP3405
Material: Si
Polaridad de transistor: NPN
ESPECIFICACIONES MÁXIMAS
Disipación total del dispositivo (Pc): 0.56
W
Tensión colector-base (Vcb): 50
V
Tensión colector-emisor (Vce): 50
V
Tensión emisor-base (Veb): 5
V
Corriente del colector DC máxima (Ic): 0.5
A
Temperatura operativa máxima (Tj): 150
°C
CARACTERÍSTICAS ELÉCTRICAS
Ganancia de corriente contínua (hfe): 180
Paquete / Cubierta:
TO92
