SS202 . Datasheet. Equivalente. Reemplazo. Hoja de especificaciones. Principales características
Número de Parte: SS202
Material: Si
Polaridad de transistor: NPN
ESPECIFICACIONES MÁXIMAS
Disipación total del dispositivo (Pc): 0.15 W
Tensión colector-base (Vcb): 120 V
Tensión colector-emisor (Vce): 120 V
Tensión emisor-base (Veb): 5 V
Corriente del colector DC máxima (Ic): 0.03 A
CARACTERÍSTICAS ELÉCTRICAS
Ganancia de corriente contínua (hfe): 32
Paquete / Cubierta: SOT23
Búsqueda de reemplazo de transistor bipolar SS202
