AP2308GEN-HF Datasheet and Replacement
Type Designator: AP2308GEN-HF
Type of Transistor: MOSFET
Type of Control Channel: N
-Channel
Pd ⓘ
- Maximum Power Dissipation: 0.69
W
|Vds|ⓘ - Maximum Drain-Source Voltage: 20
V
|Vgs|ⓘ - Maximum Gate-Source Voltage: 8
V
|Id| ⓘ - Maximum Drain Current: 1.2
A
Tj ⓘ - Maximum Junction Temperature: 150
°C
tr ⓘ - Rise Time: 36
nS
Cossⓘ -
Output Capacitance: 17
pF
Rds ⓘ - Maximum Drain-Source On-State Resistance: 0.6
Ohm
Package:
SOT23
AP2308GEN-HF substitution
-
MOSFET ⓘ Cross-Reference Search
AP2308GEN-HF Datasheet (PDF)
