AP4409GEM Datasheet. Specs and Replacement

Type Designator: AP4409GEM  📄📄

Type of Transistor: MOSFET

Type of Control Channel: P-Channel

Absolute Maximum Ratings

Pd ⓘ - Maximum Power Dissipation: 2.5 W

|Vds|ⓘ - Maximum Drain-Source Voltage: 35 V

|Vgs|ⓘ - Maximum Gate-Source Voltage: 20 V

|Id| ⓘ - Maximum Drain Current: 14.5 A

Tj ⓘ - Maximum Junction Temperature: 150 °C

Electrical Characteristics

tr ⓘ - Rise Time: 10 nS

Cossⓘ - Output Capacitance: 860 pF

RDSonⓘ - Maximum Drain-Source On-State Resistance: 0.0075 Ohm

Package: SO8

  📄📄 Copy

AP4409GEM substitution

- MOSFET ⓘ Cross-Reference Search



AP4409GEM datasheet

 ..1. Size:184K  ape
 ap4409gem.pdf pdf_icon

AP4409GEM

AP4409GEM RoHS-compliant Product Advanced Power P-CHANNEL ENHANCEMENT MODE Electronics Corp. POWER MOSFET D Simple Drive Requirement BVDSS -35V D D D Low On-resistance RDS(ON) 7.5m Fast Switching Characteristic ID -14.5A G S S S SO-8 Description D Advanced Power MOSFETs from APEC provide the designer with the best combination of fast switching, ruggedized device... See More ⇒

 6.1. Size:155K  ape
 ap4409gep.pdf pdf_icon

AP4409GEM

AP4409GEP-HF Halogen-Free Product Advanced Power P-CHANNEL ENHANCEMENT MODE Electronics Corp. POWER MOSFET Low On-resistance BVDSS -35V D Simple Drive Requirement RDS(ON) 8.2m G Fast Switching Characteristic ID -80A RoHS Compliant & Halogen-Free S Description AP4409 series are from Advanced Power innovat... See More ⇒

 6.2. Size:122K  ape
 ap4409gep-hf.pdf pdf_icon

AP4409GEM

AP4409GEP-HF Halogen-Free Product Advanced Power P-CHANNEL ENHANCEMENT MODE Electronics Corp. POWER MOSFET Low On-resistance BVDSS -35V D Simple Drive Requirement RDS(ON) 8.2m G Fast Switching Characteristic ID -80A RoHS Compliant & Halogen-Free S Description AP4409 series are from Advanced Power innovated design and silicon process technology to achieve the lowe... See More ⇒

 8.1. Size:182K  ape
 ap4409agem.pdf pdf_icon

AP4409GEM

AP4409AGEM RoHS-compliant Product Advanced Power P-CHANNEL ENHANCEMENT MODE Electronics Corp. POWER MOSFET D Simple Drive Requirement BVDSS -35V D D D Low On-resistance RDS(ON) 7.5m Fast Switching Characteristic ID -14.5A G S S S SO-8 Description D Advanced Power MOSFETs from APEC provide the designer with the best combination of fast switching, ruggedized devic... See More ⇒
