All MOSFET. 7N65 Datasheet



7N65 MOSFET. Datasheet pdf. Equivalent


   Type Designator: 7N65
   Type of Transistor: MOSFET
   Type of Control Channel: N -Channel
   Pdⓘ - Maximum Power Dissipation: 142 W
   |Vds|ⓘ - Maximum Drain-Source Voltage: 650 V
   |Vgs|ⓘ - Maximum Gate-Source Voltage: 30 V
   |Id|ⓘ - Maximum Drain Current: 7.4 A
   Tjⓘ - Maximum Junction Temperature: 150 °C
   trⓘ - Rise Time: 150 nS
   Cossⓘ - Output Capacitance: 140 pF
   Rdsⓘ - Maximum Drain-Source On-State Resistance: 0.94 Ohm
   Package: TO-220 TO-262 TO-263 TO-220F TO-220F1 TO-220F2
