Type Designator: 2N3824LP

Type of Transistor: JFET

Type of Control Channel: N -Channel

Maximum Power Dissipation (Pd): 0.3 W

Maximum Drain-Source Voltage |Vds|: 50 V

Maximum Gate-Source Voltage |Vgs|: 50 V

Maximum Drain Current |Id|: 0.012 A

Maximum Junction Temperature (Tj): 150 °C

Maximum Drain-Source On-State Resistance (Rds): 250 Ohm

Package: TO46

2N3824LP Transistor Equivalent Substitute - MOSFET Cross-Reference Search



2N3824LP Datasheet (PDF)

8.1. 2n3821 2n3822 2n3824.pdf Size:88K _central

2N3824LP
2N3824LP

145 Adams Avenue, Hauppauge, NY 11788 USATel: (631) 435-1110 Fax: (631) 435-1824

9.1. 2n3820.pdf Size:26K _fairchild_semi

2N3824LP
2N3824LP

2N3820P-Channel General Purpose Amplifier This device is designed primarily for low level audio and general purpose applications with high impedance signal sources. Sourced from process 89.TO-9211. Drain 2. Gate 3. SourceEpitaxial Silicon TransistorAbsolute Maximum Ratings* TC=25C unless otherwise noted Symbol Parameter Ratings UnitsVDG Drain-Gate Voltage -20 VVG

9.2. 2n3828.pdf Size:77K _secos

2N3824LP

2N3828 0.1 A, 40 V NPN Plastic Encapsulated Transistor Elektronische Bauelemente RoHS Compliant Product A suffix of -C specifies halogen & lead-free FEATURES General Purpose Amplifier TransistorTO-92 G H Emitter Base CollectorJA DCollectorBMillimeterREF. Min. Max.A 4.40 4.70KB 4.30 4.70 C 12.70 - D 3.30 3.81E 0

 9.3. 2n3821 2n3822.pdf Size:94K _interfet

2N3824LP

Databook.fxp 1/13/99 2:09 PM Page B-301/99 B-32N3821, 2N3822N-Channel Silicon Junction Field-Effect TransistorAbsolute maximum ratings at TA = 25C VHF AmplifiersReverse Gate Source & Reverse Gate Drain Voltage 50 V Small Signal AmplifiersContinuous Forward Gate Current 10 mAContinuous Device Power Dissipation 300 mWPower Derating 2mW/CAt 25C free air temperat

9.4. 2n3821 2n3822 2n3823.pdf Size:54K _microsemi

2N3824LP
2N3824LP

TECHNICAL DATA N-CHANNEL J-FET DEPLETION MODE Qualified per MIL-PRF-19500/375 Devices Qualified Level JANTX 2N3821 2N3822 2N3823 JANTXV MAXIMUM RATINGS 2N3821 Parameters / Test Conditions Symbol 2N3822 2N3823 Unit Gate-Source Voltage VGSR 50 30 V Drain-Source Voltage V 50 30 V DSDrain-Gate Voltage V 50 30 V DGGate Current I 10 mA GF TO-72* Power Dissipatio

Datasheet: 2N3824 , 2N3824LP , 2N4391 , 2N4391CSM , 2N4392 , 2N4392CSM , 2N4393 , 2N4393CSM , 2N7000 , 2N5045 , 2N5484 , 2N5485 , 2N5486 , 2N6656 , 2N6657 , 2N6658 , 2N6659 .
