P2003HV MOSFET. Datasheet pdf. Equivalent

   Type Designator: P2003HV
   Type of Transistor: MOSFET
   Type of Control Channel: N -Channel
   Pdⓘ - Maximum Power Dissipation: 1.9 W
   |Vds|ⓘ - Maximum Drain-Source Voltage: 30 V
   |Vgs|ⓘ - Maximum Gate-Source Voltage: 20 V
   |Vgs(th)|ⓘ - Maximum Gate-Threshold Voltage: 2.5 V
   |Id|ⓘ - Maximum Drain Current: 8 A
   Tjⓘ - Maximum Junction Temperature: 150 °C
   Qgⓘ - Total Gate Charge: 12.7 nC
   trⓘ - Rise Time: 27 nS
   Cossⓘ - Output Capacitance: 73 pF
   Rdsⓘ - Maximum Drain-Source On-State Resistance: 0.02 Ohm
   Package: SOP8

P2003HV Transistor Equivalent Substitute - MOSFET Cross-Reference Search

BUY TRANSISTORS

P2003HV Datasheet (PDF)

..1. Size:457K unikc
p2003hv.pdf

P2003HVN-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID20m @VGS = 10V30V 8ASOP-8ABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVDSDrain-Source Voltage 30VVGSGate-Source Voltage 20TA = 25 C8IDContinuous Drain CurrentTA = 70 C6AIDM40Pulsed Drain Current1IAS

9.1. Size:598K diodes
dmp2003ups.pdf

DMP2003UPS Green20V P-CHANNEL ENHANCEMENT MODE MOSFET PowerDI5060-8 Product Summary Features ID Thermally Efficient Package-Cooler Running Applications BVDSS RDS(ON) TC = +25C High Conversion Efficiency Low RDS(ON) Minimizes On State Losses 2.2m @ VGS = -10V -150A

9.2. Size:219K utc
up2003.pdf

UNISONIC TECHNOLOGIES CO., LTD UP2003 Power MOSFET 9A, 25V P-CHANNEL LOGIC LEVEL ENHANCEMENT MODE FIELD EFFECT TRANSISTOR DESCRIPTION The UP2003 uses advanced trench technology to provide excellent RDS(ON), low gate charge and operation with low gate voltages. This device is suitable for use as a load switch or in PWM applications. FEATURES * RDS(ON)

9.3. Size:491K unikc
p2003evg.pdf

P2003EVGP-Channel Logic Level Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID20m @VGS = -10V -30V -9ASOP- 08100% UIS testedABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVDSDrain-Source Voltage -30VVGSGate-Source Voltage 25TA = 25 C-9IDContinuous Drain CurrentTA = 70 C-7

9.4. Size:341K unikc
p2003bea.pdf

P2003BEAN-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID20m @VGS = 10V30V 10APDFN 3x3SABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSDrain-Source Voltage VDS30VGate-Source Voltage VGS20 TC = 25 C28 TC = 100 C18IDContinuous Drain Current TA = 25 C10A TA =

9.5. Size:354K unikc
p2003kv.pdf

P2003KVP-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID-30V 22m @VGS = -10V -8ASOP- 08ABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVDSDrain-Source Voltage -30VVGSGate-Source Voltage 25TA = 25 C-8IDContinuous Drain CurrentTA = 70 C-6AIDM-40Pulsed Drain Curren

9.6. Size:695K unikc
p2003nv.pdf

P2003NVN&P-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID Channel20m @VGS =10V30V 8.8A N25m @VGS = -10V-30V -8A PSOP-8ABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL CH. LIMITS UNITSN 30VDSDrain-Source VoltageP -30VN 20VGSGate-Source VoltageP 20N 8.8TA = 25 CP -8IDCont

9.7. Size:378K unikc
p2003ev8.pdf

P2003EV8P-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID -30V 20m @VGS = -10V -10ASOP- 08ABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVDSDrain-Source Voltage -30VVGSGate-Source Voltage 25TA = 25 C-10IDContinuous Drain CurrentTA = 70 C-8AIDM-55Pulsed Drain Cu

9.8. Size:505K unikc
p2003evt.pdf

P2003EVTP-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID20m @VGS = -10V -30V -9A100% UIS testedSOP- 08ABSOLUTE MAXIMUM RATINGS (TC = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVDSDrain-Source Voltage -30VVGSGate-Source Voltage 25TC = 25 C-9IDContinuous Drain CurrentTC = 70 C-8AIDM-32

9.9. Size:523K unikc
p2003beaa.pdf

P2003BEAAN-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID20m @VGS = 10V30V 25APDFN 3X3PABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVDSDrain-Source Voltage 30VVGSGate-Source Voltage 20Tc = 25 C25Tc = 100 C16IDContinuous Drain CurrentTA = 25 C8ATA= 70

9.10. Size:492K unikc
p2003etf.pdf

P2003ETFP-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID20m @VGS = -10V-30V -26ATO-220F ABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVDSDrain-Source Voltage -30VVGSGate-Source Voltage 25TC = 25 C-26IDContinuous Drain CurrentTC = 100 C-16AIDM-120Pulsed Drai

9.11. Size:500K unikc
p2003bvg.pdf

P2003BVGN-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID20m @VGS = 10V30V 9ASOP-8ABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVDSDrain-Source Voltage 30VVGSGate-Source Voltage 25TA = 25 C9IDContinuous Drain CurrentTA = 70 C7AIDM32Pulsed Drain Current1IAS

9.12. Size:475K unikc
p2003bt.pdf

P2003BTN-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID20m @VGS = 10V30V 39ATO-220ABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVDSDrain-Source Voltage 30VVGSGate-Source Voltage 20TC = 25 C39IDContinuous Drain CurrentTC = 100 C25AIDM120Pulsed Drain Current1

9.13. Size:457K unikc
p2003ed.pdf

P2003EDP-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID20m @VGS = -10V-30V -36ATO-252ABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVDSDrain-Source Voltage -30VVGSGate-Source Voltage 25TC = 25 C-36IDContinuous Drain CurrentTC = 100 C-23AIDM-100Pulsed Drain C

9.14. Size:468K unikc
p2003bdg.pdf

P2003BDGN-Channel Logic Level Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID20m @VGS = 10V25V 28ATO-252ABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVDSDrain-Source Voltage 25VVGSGate-Source Voltage 20TC= 25 C28IDContinuous Drain CurrentTC= 100 C18AIDM90Pulsed Drai

9.15. Size:499K unikc
p2003be.pdf

P2003BEN-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID20m @VGS = 10V30V 7APDFN 3x3SABSOLUTE MAXIMUM RATINGS (TJ = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVDSDrain-Source Voltage 30VVGSGate-Source Voltage 20 TC = 25 C25 TC = 100 C15IDContinuous Drain Current TA = 25 C7A TA = 70

9.16. Size:547K unikc
p2003bvt.pdf

P2003BVTN-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID20m @VGS = 10V30V 9A100% Rg tested100% UIS testedSOP-8ABSOLUTE MAXIMUM RATINGS (TC = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVDSDrain-Source Voltage 30VVGSGate-Source Voltage 20TA = 25 C9IDContinuous Drain CurrentTA = 70 C7AID

9.17. Size:530K unikc
p2003eea.pdf

P2003EEAP-Channel Logic Level Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID20m @VGS = -10V -30V -28APDFN 3x3PABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVDSDrain-Source Voltage -30VVGSGate-Source Voltage 25 TC = 25 C-28 TC = 100 C-18IDContinuous Drain Current2 TA = 25

9.18. Size:485K unikc
p2003eeaa.pdf

P2003EEAAP-Channel Logic Level Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID20m @VGS = -10V -30V -25APDFN 3x3PABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVDSDrain-Source Voltage -30VVGSGate-Source Voltage 20 TC = 25 C-25 TC = 100 C-16IDContinuous Drain Current2 TA = 2

9.19. Size:475K unikc
p2003bv.pdf

P2003BVN-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID20m @VGS = 10V30V 8.5ASOP- 08ABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVGSGate-Source Voltage 20 VTA = 25 C8.5IDContinuous Drain CurrentTA = 70 C6.8AIDM30Pulsed Drain Current1IASAvalanche Current 17

9.20. Size:363K unikc
p2003ev.pdf

P2003EVP-Channel Enhancement Mode MOSFETPRODUCT SUMMARYV(BR)DSS RDS(ON) ID20m @VGS = -10V -30V -9ASOP- 08ABSOLUTE MAXIMUM RATINGS (TA = 25 C Unless Otherwise Noted)PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSVDSDrain-Source Voltage -30VVGSGate-Source Voltage 25TA = 25 C-9IDContinuous Drain CurrentTA = 70 C-7AIDM-45Pulsed Drain Curr

9.21. Size:312K niko-sem
p2003evg.pdf

P-Channel Logic Level Enhancement P2003EVGNIKO-SEM Mode Field Effect Transistor SOP-8 Halogen-Free & Lead-FreeD4 :GATE PRODUCT SUMMARY 5,6,7,8 :DRAIN 1,2,3 :SOURCEV(BR)DSS RDS(ON) ID G-30 20m -9A S100% UIS testedABSOLUTE MAXIMUM RATINGS (TC = 25 C Unless Otherwise Noted) PARAMETERS/TEST CONDITIONS SYMBOL LIMITS UNITSDrain-Source Voltage VDS -30 VGate-Sou
