AP3P080N MOSFET. Datasheet pdf. Equivalent
Type Designator: AP3P080N
Marking Code: A10SS
Type of Transistor: MOSFET
Type of Control Channel: P -Channel
Pdⓘ - Maximum Power Dissipation: 1.25 W
|Vds|ⓘ - Maximum Drain-Source Voltage: 30 V
|Vgs|ⓘ - Maximum Gate-Source Voltage: 12 V
|Vgs(th)|ⓘ - Maximum Gate-Threshold Voltage: 1.2 V
|Id|ⓘ - Maximum Drain Current: 3.2 A
Tjⓘ - Maximum Junction Temperature: 150 °C
Qgⓘ - Total Gate Charge: 8.5 nC
trⓘ - Rise Time: 10 nS
Cossⓘ - Output Capacitance: 85 pF
Rdsⓘ - Maximum Drain-Source On-State Resistance: 0.06 Ohm
Package: SOT23S
AP3P080N Transistor Equivalent Substitute - MOSFET Cross-Reference Search
AP3P080N Datasheet (PDF)
ap3p080n.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AP3P080NHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Capable of 2.5V Gate Drive BVDSS -30VD Small Package Outline RDS(ON) 80m Surface Mount Device ID -3.2AS RoHS Compliant & Halogen-FreeSOT-23SGDDescriptionAP3P080 series are from Advanced Power innovated designand silicon process technology to achieve the
ap3p050h.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AP3P050HHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Lower Gate Charge BVDSS -30VD Simple Drive Requirement RDS(ON) 50mG Fast Switching Characteristic ID -15A RoHS Compliant & Halogen-FreeSDescriptionAP3P050 series are from Advanced Power innovated design and GDSsilicon process technology to achieve the l
ap3p010yt.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AP3P010YTHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Low Gate Charge BVDSS -30VD Fast Switching Characteristic RDS(ON) 10m Simple Drive Requirement ID -14.6A RoHS Compliant & Halogen-Free GSDDDescriptionDAdvanced Power MOSFETs from APEC provide the designer with theDbest combination of fast switching,
ap3p010amt.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AP3P010AMTHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% Rg & UIS Test BVDSS -30VD Simple Drive Requirement RDS(ON) 10m Fast Switching Characteristic ID -58A RoHS Compliant & Halogen-Free GSDDescriptionDDAP3P010A series are from Advanced Power innovated design andDsilicon process technology to achiev
ap3p010h.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AP3P010HHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET 100% UIS Test D BVDSS -30V Simple Drive Requirement RDS(ON) 10m Fast Switching Characteristic ID -58AG RoHS Compliant & Halogen-FreeSDescriptionGAP3P010 series are from Advanced Power innovated design andDSsilicon process technology to achieve the lowes
ap3p028lm.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AP3P028LMHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Low Gate Charge D BVDSS -30V Fast Switching Characteristic RDS(ON) 28m Capable of 2.5V Gate Drive ID3 -7.7AG RoHS Compliant & Halogen-FreeSDescriptionDDAP3P028L series are from Advanced Power innovated design andDDsilicon process technology to achiev
ap3p050m.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AP3P050MHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Low Gate Charge BVDSS -30VD Fast Switching Characteristic RDS(ON) 50mG Simple Drive Requirement ID3 -5.6A RoHS Compliant & Halogen-FreeSDescriptionDDAP3P050 series are from Advanced Power innovated design and siliconDDprocess technology to achieve t
ap3p010m.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AP3P010MHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Low Gate Charge D BVDSS -30V Fast Switching Characteristic RDS(ON) 10m Simple Drive Requirement ID3 -13.3AG RoHS Compliant & Halogen-FreeSDescriptionDDAP3P010 series are from Advanced Power innovated design and siliconDDprocess technology to achieve t
ap3p090n.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AP3P090NHalogen-Free ProductAdvanced Power P-CHANNEL ENHANCEMENT MODEElectronics Corp. POWER MOSFET Simple Drive Requirement BVDSS -30VD Small Package Outline RDS(ON) 90m Surface Mount Device ID3 -3.1AS RoHS Compliant & Halogen-FreeSOT-23SGDDescriptionAP3P090 series are from Advanced Power innovated designand silicon process technology to achieve the
