JMSL0604AGQ Datasheet and Replacement
Type Designator: JMSL0604AGQ
Type of Transistor: MOSFET
Type of Control Channel: N
-Channel
Pd ⓘ
- Maximum Power Dissipation: 100
W
|Vds|ⓘ - Maximum Drain-Source Voltage: 60
V
|Vgs|ⓘ - Maximum Gate-Source Voltage: 20
V
|Id| ⓘ - Maximum Drain Current: 112
A
Tj ⓘ - Maximum Junction Temperature: 175
°C
tr ⓘ - Rise Time: 7.8
nS
Cossⓘ -
Output Capacitance: 445
pF
Rds ⓘ - Maximum Drain-Source On-State Resistance: 0.0045
Ohm
Package:
PDFN5X6-8L
-
MOSFET ⓘ Cross-Reference Search
JMSL0604AGQ Datasheet (PDF)
