BLM3404 Datasheet. Specs and Replacement
Type Designator: BLM3404 📄📄
Type of Transistor: MOSFET
Type of Control Channel: N-Channel
Absolute Maximum Ratings
Pd ⓘ - Maximum Power Dissipation: 1.4 W
|Vds|ⓘ - Maximum Drain-Source Voltage: 30 V
|Vgs|ⓘ - Maximum Gate-Source Voltage: 20 V
|Id| ⓘ - Maximum Drain Current: 5.8 A
Tj ⓘ - Maximum Junction Temperature: 150 °C
Electrical Characteristics
tr ⓘ - Rise Time: 2.5 nS
Cossⓘ - Output Capacitance: 45 pF
RDSonⓘ - Maximum Drain-Source On-State Resistance: 0.031 Ohm
Package: SOT23
📄📄 Copy
BLM3404 substitution
- MOSFET ⓘ Cross-Reference Search
BLM3404 datasheet
blm3400.pdf
Pb Free Product BLM3400 N-Channel Enhancement Mode Power MOSFET DESCRIPTION The BLM3400 uses advanced trench technology to provide D excellent R , low gate charge and operation with gate DS(ON) voltages as low as 2.5V. This device is suitable for use as a G Battery protection or in other Switching application. S GENERAL FEATURES V = 30V,I = 5.8A Schematic diagram DS ... See More ⇒
blm3401.pdf
P-Channel Enhancement BLM3401 Mode MOSFET BLM3401 BLM3401 BLM3401 FEATURES APPLICATIONS VDS VGS RDSon TYP ID Load Switch 51mR@-10V 4A Portable Devices 30V 12V 60mR@-4V5 DCDC conversion 98mR@-2V5 Pin Configuration DESCRIPTION This device is particularly suited for low voltage application such as portable equipment, power management and other ... See More ⇒
Detailed specifications: BMDFN2301, BMDFN2302, BMS2301, BMS2302, BMSN3139, SI2301F, SI2309S, BL4N90, 50N06
