AON7408 MOSFET - описание производителя. Даташиты. Основные параметры и характеристики. Поиск аналога. Справочник
Наименование прибора: AON7408
Тип транзистора: MOSFET
Полярность: N
Максимальная рассеиваемая мощность (Pd): 11 W
Предельно допустимое напряжение сток-исток |Uds|: 30 V
Предельно допустимое напряжение затвор-исток |Ugs|: 20 V
Пороговое напряжение включения |Ugs(th)|: 2.6 V
Максимально допустимый постоянный ток стока |Id|: 18 A
Максимальная температура канала (Tj): 150 °C
Общий заряд затвора (Qg): 7.1 nC
Время нарастания (tr): 2.8 ns
Выходная емкость (Cd): 67 pf
Сопротивление сток-исток открытого транзистора (Rds): 0.02 Ohm
Тип корпуса: DFN3X3EP
AON7408 Datasheet (PDF)
aon7408.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON740830V N-Channel MOSFETGeneral Description Product SummaryVDS30V The AON7408 uses advanced trench technology anddesign to provide excellent RDS(ON) with low gate charge. ID (at VGS=10V) 18AThis device is suitable for use in general purpose RDS(ON) (at VGS=10V)
aon7408.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON740830V N-Channel MOSFETGeneral Description Product SummaryVDS30V The AON7408 uses advanced trench technology anddesign to provide excellent RDS(ON) with low gate charge. ID (at VGS=10V) 18AThis device is suitable for use in general purpose RDS(ON) (at VGS=10V)
aon7405.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON740530V P-Channel MOSFETGeneral Description Product SummaryVDS-30VThe AON7405 uses advanced trench technology toprovide excellent RDS(ON) with low gate charge. ID (at VGS= -10V) -50AThis device is ideal for load switch and battery protection RDS(ON) (at VGS= -10V)
aon7406.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON740630V N-Channel MOSFETGeneral Description Product SummaryVDS30V The AON7406 uses advanced trench technology anddesign to provide excellent RDS(ON) with low gate charge. ID (at VGS=10V) 25AThis device is suitable for use in SMPS and general RDS(ON) (at VGS=10V)
aon7403.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON740330V P-Channel MOSFETGeneral Description Product SummaryVDS-30VThe AON7403 uses advanced trench technology toprovide excellent RDS(ON), and ultra-low low gate charge ID (at VGS=-10V) -29Awith a 25V gate rating. This device is suitable for use as a RDS(ON) (at VGS=-10V)
aon7400a.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON7400A30V N-Channel MOSFETGeneral Description Product SummaryVDS30V The AON7400A combines advanced trench MOSFETtechnology with a low resistance package to provide ID (at VGS=10V) 40Aextremely low RDS(ON). This device is suitable for use as a RDS(ON) (at VGS=10V)
aon7409.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON740930V P-Channel MOSFETGeneral Description Product SummaryVDS The AON7409 combines advanced trench MOSFET -30Vtechnology with a low resistance package to provide ID (at VGS=-10V) -32Aextremely low RDS(ON). This device is ideal for load switch RDS(ON) (at VGS=-10V)
aon7401.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON740130V P-Channel MOSFETGeneral Description Product SummaryVDS-30VThe AON7401 uses advanced trench technology toprovide excellent RDS(ON), and ultra-low low gate charge ID (at VGS=-10V) -35Awith a 25V gate rating. This device is suitable for use as a RDS(ON) (at VGS=-10V)
aon7407.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON740720V P-Channel MOSFETGeneral Description Product SummaryVDS -20VThe AON7407 combines advanced trench MOSFETtechnology with a low resistance package to provide ID (at VGS=-4.5V) -40Aextremely low RDS(ON). This device is ideal for load switch RDS(ON) (at VGS =-4.5V)
aon7400.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON740030V N-Channel MOSFETGeneral Description Product SummaryVDS30VThe AON7400 uses advanced trench technology anddesign to provide excellent RDS(ON) with low gate charge. ID (at VGS=10V) 26AThis device is suitable for use in DC - DC converters and RDS(ON) (at VGS=10V)
aon7405.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON740530V P-Channel MOSFETGeneral Description Product SummaryVDS-30VThe AON7405 uses advanced trench technology toprovide excellent RDS(ON) with low gate charge. ID (at VGS= -10V) -50AThis device is ideal for load switch and battery protection RDS(ON) (at VGS= -10V)
aon7402.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON740230V N-Channel MOSFETGeneral Description Product SummaryVDS30VThe AON7402 uses advanced trench technology toprovide excellent RDS(ON) with low gate charge. ID (at VGS=10V) 39AThis device is suitable for high side switch in SMPS and RDS(ON) (at VGS=10V)
aon7406.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON740630V N-Channel MOSFETGeneral Description Product SummaryVDS30V The AON7406 uses advanced trench technology anddesign to provide excellent RDS(ON) with low gate charge. ID (at VGS=10V) 25AThis device is suitable for use in SMPS and general RDS(ON) (at VGS=10V)
aon7403.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON740330V P-Channel MOSFETGeneral Description Product SummaryVDS-30VThe AON7403 uses advanced trench technology toprovide excellent RDS(ON), and ultra-low low gate charge ID (at VGS=-10V) -29Awith a 25V gate rating. This device is suitable for use as a RDS(ON) (at VGS=-10V)
aon7400a.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON7400A30V N-Channel MOSFETGeneral Description Product SummaryVDS30V The AON7400A combines advanced trench MOSFETtechnology with a low resistance package to provide ID (at VGS=10V) 40Aextremely low RDS(ON). This device is suitable for use as a RDS(ON) (at VGS=10V)
aon7409.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON740930V P-Channel MOSFETGeneral Description Product SummaryVDS The AON7409 combines advanced trench MOSFET -30Vtechnology with a low resistance package to provide ID (at VGS=-10V) -32Aextremely low RDS(ON). This device is ideal for load switch RDS(ON) (at VGS=-10V)
aon7401.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON740130V P-Channel MOSFETGeneral Description Product SummaryVDS-30VThe AON7401 uses advanced trench technology toprovide excellent RDS(ON), and ultra-low low gate charge ID (at VGS=-10V) -35Awith a 25V gate rating. This device is suitable for use as a RDS(ON) (at VGS=-10V)
aon7404g.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON7404G20V N-Channel MOSFETGeneral Description Product SummaryVDS Trench Power MOSFET technology 20V Low RDS(ON) ID (at VGS=4.5V) 20A RoHS and Halogen-Free Compliant RDS(ON) (at VGS=4.5V)
aon7407.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON740720V P-Channel MOSFETGeneral Description Product SummaryVDS -20VThe AON7407 combines advanced trench MOSFETtechnology with a low resistance package to provide ID (at VGS=-4.5V) -40Aextremely low RDS(ON). This device is ideal for load switch RDS(ON) (at VGS =-4.5V)
aon7404.pdf
![](https://alltransistors.com/ad/pdf_icon.gif)
AON740420V N-Channel MOSFETGeneral Description Product SummaryVDS20VThe AON7404 combines advanced trench MOSFETtechnology with a low resistance package to provide ID (at VGS=4.5V) 20Aextremely low RDS(ON). This device is ideal for load switch RDS(ON) (at VGS=4.5V)
