Справочник транзисторов. M1



Биполярный транзистор M1 - описание производителя. Основные параметры. Даташиты.


   Наименование производителя: M1
   Тип материала: Ge
   Полярность: PNP
   Максимальная рассеиваемая мощность (Pc): 0.1 W
   Макcимально допустимое напряжение коллектор-база (Ucb): 25 V
   Макcимальный постоянный ток коллектора (Ic): 0.012 A
   Предельная температура PN-перехода (Tj): 75 °C
   Ёмкость коллекторного перехода (Cc): 1.4 pf
   Статический коэффициент передачи тока (hfe): 20
   Корпус транзистора: CAN
