Биполярный транзистор TK2907ATTD03
- описание производителя. Основные параметры. Даташиты.
Наименование производителя: TK2907ATTD03
Маркировка: 2F
Тип материала: Si
Полярность: PNP
Максимальная рассеиваемая мощность (Pc): 0.15
W
Макcимально допустимое напряжение коллектор-база (Ucb): 60
V
Макcимально допустимое напряжение коллектор-эмиттер (Uce): 60
V
Макcимально допустимое напряжение эмиттер-база (Ueb): 5
V
Макcимальный постоянный ток коллектора (Ic): 0.6
A
Предельная температура PN-перехода (Tj): 150
°C
Граничная частота коэффициента передачи тока (ft): 200
MHz
Ёмкость коллекторного перехода (Cc): 8
pf
Статический коэффициент передачи тока (hfe): 100
Корпус транзистора: WBFBP-03A
Аналоги (замена) для TK2907ATTD03
TK2907ATTD03
Datasheet (PDF)
..1. Size:97K jiangsu
tk2907attd03.pdf
JIANGSU CHANGJIANG ELECTRONICS TECHNOLOGY CO.,LTD WBFBP-03A Plastic-Encapsulate Transistors C TK2907ATTD03 TRANSISTOR WBFBP-03A (1.61.60.5) TOP unit: mm DESCRIPTION PNP Epitaxial planar type Silicon Transistor B E FEATURES 1. BASE C Complementary NPN Type available (TK2222ATTD03) 2. EMITTER 3. COLLECTOR BACK PPLICATION general purpose amplifier, swit
